INSTALLATION INSTRUCTIONS - OUTSIDE TOP EXHAUST
Use these instructions if the appliance will be vented to the outside through the top of the appliance.
Install the mounting plate
Use a 5/8” drill to make two holes that will enter the drywall. Use a 3/16” drill to make a hole that will
enter a wall stud. Use the mounting template to decide the location of the holes. At least one hole must
enter a wall stud.
Insert the machine screws into the mounting plate through the holes designed to go into drywall and attach
the wing nuts 3/4” onto each machine screw.
Place the mounting plate against the wall and insert the wing nuts into the holes in the wall. The wing nuts
will open on the other side of the wall to secure the screw.
Do not place a wing nut on the screw that will go into the wall stud. Insert a wood screw through the
mounting plate and into the wall stud. Tighten all screws.
Plate
Wall
Wing nut
machine
screw
Bolt End
Spacing for Toggles More
Than Wall Thickness
5⁄8"
11
