Multi-Contact MA130 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 4
KT425-ZL
50.1138-*
(1+2+3+7) LS425-ZL
49.2030
(4) LS425-ZL/M3
49.2029
(5)
FLEXI-E 2,5
60.7012-*
SILI-E 2,5
61.7556-*
green-y
ello
w
black red blue yello
w
green violet bro
wn
gre
y
white transparent
2 0 21 22 23 24 25 26 27 28 29 33
* Available colours: 21-25 + 29
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA130 (fr_en)
Notice de montage MA130 (fr_en)
Assembly instructions
Fiches Ø 4mm droites SLS425-ZL, SLS425-ZL/M3 In-line Ø 4mm plugs SLS425-ZL, SLS425-ZL/M3
Sommaire
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Préparation du câble ..................................................................3
Souder .......................................................................................3
Visser .........................................................................................3
Montage ....................................................................................4 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Preparation of the cable ............................................................3
Soldering ...................................................................................3
Screwing ...................................................................................3
Assembly ...................................................................................4
* Couleurs disponibles: 21-25 + 29
vert
-jaune
noir rouge bleu jaune vert violet brun gris blanc transparent
2 0 21 22 23 24 25 26 27 28 29 33
