Multi-Contact MA101 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 4
1
3
6
7 5 2/4
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA101 (fr_en)
Notice de montage MA101 (fr_en)
Assembly instructions
Porte-câbles LKH
No. de Cde 25.0001 Connecting lead holder LKH
Order No. 25.0001
Sommaire
Consignes de sécurité ................................................................2
Montage ....................................................................................4 Content
Safety Instructions ....................................................................2
Assembly ...................................................................................4
Pos. Type Désignation
Description No. de Cde
Order No.
1 LKH-S
1 rail de fi xation
1 clamp rail
25.5004
2 LKH-Sch
2 vis à bois
2 wood screws
25.5008
3 LKH-D
2 chevilles
2 wall plugs
25.5009
4 LKH-BSch
2 vis pour métal
2 sheet metal screws
25.5010
5 LKH-A
1 rail d‘ancrage
1 bracket holder
25.5001
6 LKH-K
21 supports en matière plastique
21 plastic hooks
25.5003
7 LKH-B
21 vis de fi xation
21 fi xing bolts
25.5005
