MODE SURROUND
Cet appareil est équipé de nombreux modes Surround.
Ils permettent de reproduire une diversité d’effets de son Surround, en fonction du contenu de la source à écouter.
Les modes Surround disponibles peuvent être limités, selon le signal d’entrée et la confi guration des enceintes.
RELATION ENTRE LE MODE SURROUND SÉLECTIONNÉ ET LE SIGNAL D’ENTRÉE
Le mode Surround est sélectionné avec le sélecteur de mode Surround sur l’appareil ou la télécommande.
Le son que vous entendez dépend toutefois de la relation entre le mode Surround sélectionné et le signal
d’entrée. Cette relation est la suivante:
AUTRES
Mode
Surround
Signal d’entrée Décodage
Canal de sortie Affi chage d’informations avant
L/R C SL
SR HL
HR SBL
SBR SubW Témoins de format du
signal Etat des canaux
AUTO Dolby Surr.EX Dolby Digital EX ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 ‡ ‡ ‡ – – ‡ 2 DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Digital 2.0 ‡ – – – – ‡ 2 DIGITAL L, R
Dolby D (2ch Surr) Pro Logic IIx movie ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, R, S
Dolby Digital Plus (2ch) DolbyDigital + ‡ – – – – ‡ 2 DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital + ‡ ‡ ‡ – – ‡ 2 DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch) DolbyDigital + ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, C, R, SL, SR, S, LFE (,ex1)
Dolby Digital Plus (7.1ch) DolbyDigital + ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) DolbyTrueHD ‡ – – – – ‡ 2 TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD ‡ ‡ ‡ – – ‡ 2 TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) DolbyTrueHD ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, C, R, SL, SR, S, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) DolbyTrueHD ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
Dolby TrueHD 192kHz (5.1ch) DolbyTrueHD ‡ ‡ ‡ – – ‡ 2 TrueHD L, C, R, SL, SR, LFE
DTS-ES DTS-ES ‡ ‡ ‡ – ‡ ‡ dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24 ‡ ‡ ‡ – – ‡ dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 ‡ ‡ ‡ – – ‡ dts L, C, R, SL, SR, LFE
DTS-HD (2ch) DTS-HD ‡ – – – – ‡ dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD ‡ ‡ ‡ – – ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
DTS Express DTS EXPRESS ‡ ‡ ‡ – – ‡ dts express L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM ‡ ‡ ‡ – – ‡ PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz ‡ ‡ ‡ – – ‡ PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 192kHz Multi Ch-PCM 192kHz ‡ ‡ ‡ – – ‡ PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) ‡ ‡ ‡ – – ‡ DSD L, C, R, SL, SR, LFE
SA-CD (2ch) SA-CD (Stereo) ‡ – – – – ‡ DSD L, R
PCM (Audio) PCM (Stereo) ‡ – – – – ‡ PCM L, R
PCM 96kHz PCM (Stereo 96kHz) ‡ – – – – ‡ PCM L, R
HDCD HDCD ‡ – – – – ‡ PCM, HDCD L, R
Analog Stereo ‡ – – – – ‡ ANALOG -
7.1ch input Multi Ch ‡ ‡ ‡ – ‡ ‡ ANALOG -
SOURCE
DIRECT
PURE DIRECT Dolby Surr.EX Dolby Digital EX ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 ‡ ‡ ‡ – – ‡ 2 DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Digital 2.0 ‡ – – – – – 2 DIGITAL L, R
Dolby D (2ch Surr) Pro Logic IIx movie ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, R, S
Dolby Digital Plus (2ch) DolbyDigital + ‡ – – – – – 2 DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital + ‡ ‡ ‡ – – ‡ 2 DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch) DolbyDigital + ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, C, R, SL, SR, S, LFE (,ex1)
Dolby Digital Plus (7.1ch) DolbyDigital + ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) DolbyTrueHD ‡ – – – – – 2 TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD ‡ ‡ ‡ – – ‡ 2 TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) DolbyTrueHD ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, C, R, SL, SR, S, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) DolbyTrueHD ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
Dolby TrueHD 192kHz (5.1ch) DolbyTrueHD ‡ ‡ ‡ – – ‡ 2 TrueHD L, C, R, SL, SR, LFE
DTS-ES DTS-ES ‡ ‡ ‡ – ‡ ‡ dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24 ‡ ‡ ‡ – – ‡ dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 ‡ ‡ ‡ – – ‡ dts L, C, R, SL, SR, LFE
DTS-HD (2ch) DTS-HD ‡ – – – – – dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD ‡ ‡ ‡ – – ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
DTS Express DTS EXPRESS ‡ ‡ ‡ – – ‡ dts express L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM ‡ ‡ ‡ – – ‡ PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz ‡ ‡ ‡ – – ‡ PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 192kHz Multi Ch-PCM 192kHz ‡ ‡ ‡ – – ‡ PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) ‡ ‡ ‡ – – ‡ DSD L, C, R, SL, SR, LFE
Mode
Surround
Signal d’entrée Décodage
Canal de sortie Affi chage d’informations avant
L/R C SL
SR HL
HR SBL
SBR SubW Témoins de format du
signal Etat des canaux
SOURCE
DIRECT
PURE DIRECT SA-CD (2ch) SA-CD (Stereo) ‡ – – – – ‡ DSD L, R
PCM (Audio) PCM (Stereo) ‡ – – – – – PCM L, R
PCM 96kHz PCM (Stereo 96kHz) ‡ – – – – – PCM L, R
HDCD HDCD ‡ – – – – – PCM, HDCD L, R
Analog Stereo ‡ – – – – – ANALOG -
7.1ch input Multi Ch ‡ ‡ ‡ – ‡ ‡ ANALOG -
EX/ES Dolby Surr.EX Dolby Digital EX ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital EX ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, C, R, SL, SR, LFE
Dolby Digital Plus (5.1ch) DolbyDigital + +EX ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby TrueHD (5.1ch) DolbyTrueHD +EX ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-ES DTS-ES ‡ ‡ ‡ – ‡ ‡ dts, ES L, C, R, SL, SR, S, LFE
DTS (5.1ch) DTS-ES ‡ ‡ ‡ – ‡ ‡ dts L, C, R, SL, SR, LFE
DTS-HD (5.1) DTS-HD + NEO6 ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
Multi-PCM
Multi Ch-PCM +
Dolby Digital EX ‡ ‡ ‡ – ‡ ‡ PCM L, C, R, SL, SR, SW
SA-CD (5.1ch)
SA-CD (5.1ch) +
Dolby Digital EX ‡ ‡ ‡ – ‡ ‡ DSD L, C, R, SL, SR, SW
DOLBY PLIIz Dolby Surr.EX Dolby Digital 5.1 + PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1+ +
PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL L, R
Dolby D (2ch Surr) PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL L, R, S
Dolby Digital Plus (2ch) PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital Plus + PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch) DolbyDigital Plus + PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL PLUS L, C, R, SL, SR, S,LFE
Dolby Digital Plus (7.1ch) DolbyDigital Plus + PLIIz ‡ ‡ ‡ ‡ – ‡ 2 DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) PLIIz ‡ ‡ ‡ ‡ – ‡ 2 TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD + PLIIz ‡ ‡ ‡ ‡ – ‡ 2 TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) DolbyTrueHD + PLIIz ‡ ‡ ‡ – – ‡ 2 TrueHD L, C, R, SL, SR, S, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) DolbyTrueHD + PLIIz ‡ ‡ ‡ ‡ – ‡ 2 TrueHD L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
DTS-HD (2ch) PLIIz ‡ ‡ ‡ ‡ – ‡ 2 TrueHD L, R
Multi Ch-PCM Multi Ch-PCM + PLIIz ‡ ‡ ‡ ‡ – ‡ PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) + PLIIz ‡ ‡ ‡ ‡ – ‡ DSD L, C, R, SL, SR, LFE
SA-CD (2ch) PLIIz ‡ ‡ ‡ ‡ – ‡ DSD L, R
PCM (Audio) PLIIz ‡ ‡ ‡ ‡ – ‡ PCM L, R
HDCD PLIIz ‡ ‡ ‡ ‡ – ‡ PCM, HDCD L, R
Analog PLIIz ‡ ‡ ‡ ‡ – ‡ ANALOG –
DOLBY
(PLIIx movie)
(PLIIx music)
(PLIIx game) Dolby Surr.EX Dolby Digital EX ‡ ‡ ‡ – – ‡ 2 DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1 ‡ ‡ ‡ – – ‡ 2 DIGITAL L, C, R, SL, SR, LFE
Dolby D (5.1ch) Dolby Digital 5.1 + PLIIx ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, R
Dolby D (2ch Surr) Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, R, S
Dolby Digital Plus (2ch) Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital + ‡ ‡ ‡ – – ‡ 2 DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (5.1ch) Dolby Digital Plus + PLIIx ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby TrueHD (2ch) Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD + PLIIx ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (5.1ch) DolbyTrueHD ‡ ‡ ‡ – – ‡ 2 TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (2ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, R
Multi Ch-PCM Multi Ch-PCM + PLIIx ‡ ‡ ‡ – ‡ ‡ PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) + PLIIx ‡ ‡ ‡ – ‡ ‡ DSD L, C, R, SL, SR, LFE
SA-CD (2ch) Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ DSD L, R
PCM (Audio) Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ PCM L, R
HDCD Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ PCM, HDCD L, R
Analog Pro Logic IIx ‡ ‡ ‡ – ‡ ‡ ANALOG -
DTS
(Neo:6
Cinema)
(Neo:6 Music) DTS-ES DTS 5.1 ‡ ‡ ‡ – – ‡ dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24 ‡ ‡ ‡ – – ‡ dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1 ‡ ‡ ‡ – – ‡ dts L, C, R, SL, SR, LFE
DTS-HD (2ch) Neo:6 ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD ‡ ‡ ‡ – – ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD ‡ ‡ ‡ – ‡ ‡ dts-HD MSTR/HIRES L, C, R, SL, SR, SBL, SBR, LFE
(,ex1,ex2)
Dolby D (2ch) Neo:6 ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, R
Dolby D (2ch Surr) Neo:6 ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL L, R, S
Dolby Digital Plus (2ch) Neo:6 ‡ ‡ ‡ – ‡ ‡ 2 DIGITAL PLUS L, R
Dolby TrueHD (2ch) Neo:6 ‡ ‡ ‡ – ‡ ‡ 2 TrueHD L, R
SA-CD (2ch) Neo:6 ‡ ‡ ‡ – ‡ ‡ DSD L, R
PCM (Audio) Neo:6 ‡ ‡ ‡ – ‡ ‡ PCM L, R
HDCD Neo:6 ‡ ‡ ‡ – ‡ ‡ PCM, HDCD L, R
Analog Neo:6 ‡ ‡ ‡ – ‡ ‡ ANALOG -
