4
5-2
powermax1250
Service manuel
NOMENCLATURE DES PIÈCES – TORCHE ET CONSOMMABLES
Torche manuelle T80
Numéro
Article de référence Description Qté
087001* T80 hand torch assembly with 25 ft (7.6 m) lead
087002* T80 hand torch assembly with 50 ft (15.2 m) lead
087047* T80 hand torch assembly with 75 ft (22.5 m) lead
1 128564 Kit: T80 torch main body replacement 1
2 027889 Retaining clip 1
3 058519 O-ring 1
4 128639 Kit: Cap-off sensor replacement 1
5 075571 Cap-off sensor screws 2
6 128521 Kit: T80/T80M torch head replacement 1
7 128644 Kit: Handle replacement 1
8 075586 Handle screws 5
9 002244 Safety trigger assembly 1
10 027254 Spring 1
11 128637 Kit: T80 25 ft (7.6 m) torch lead replacement 1
12 128636 Kit: T80 50 ft (15.2 m) torch lead replacement 1
13 128893 Kit: T80 75 ft (22.5 m) torch lead replacement 1
14 128638 Kit: ETR connector replacement 1
15 128642 Kit: T80 start switch replacement 1
* L’ensemble supérieur comprend les consommables suivants (voir les Configurations des consommables de la
T80 qui donne les descriptions des pièces consommable) :
120926 Electrode 1
120925 Swirl ring 1
120928 Retaining cap 1
120929 Shield 1
120927 Nozzle 1
