Chapter 6 : EVENTIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
CENTRIX™ & EVENTIX™
PAGE 50
6-5. LCD FUNCTIONS DESCRIPTION (continued)
4
[IMAGE] + ENTER.
Select an output between MAIN & PREVIEW with + ENTER.
NOTE: The image menu contents will be different in case of computer or video on the input selected.
4-1
[centering] + ENTER.
Adjust automatically the image in the centering pattern.
4-2
[pos settings] + ENTER.
Adjust the image position with H and V knobs and validate with ENTER.
4-3
[size settings] + ENTER.
Adjust the image size with H and V knobs and validate with ENTER.
4-4
[aspect ratio] + ENTER.
Select the Aspect Ratio of your input source or the zoom mode with + ENTER.
• [4/3 standard]: 4/3 input format.
• [16/9 letterbox]: Letterbox input format.
• [WS anamorphic]: Widescreen anamorphic input format (video) or 16/9 input format (computer).
• [zoom]: Allows zooming in the image.
• If the selected input is a VIDEO signal the IMAGE MENU displays the following items:
4-5
[brightness] + ENTER.
Adjust the Brightness with + ENTER.
4-6
[contrast] + ENTER.
Adjust the Contrast with + ENTER.
4-7
[color] + ENTER.
Adjust the Color with + ENTER.
4-8
[hue] + ENTER.
Adjust the Tint of the picture (NTSC only) with + ENTER.
4-9
[under / over] + ENTER.
• [underscan]: Underscan mode. The entire image is visible on the screen. Computer mode is underscan.
• [overscan]: Overscan mode. The image is displayed about 8 % bigger than in underscan mode, to avoid
seeing the corners and the borders. Standard TV display mode is overscan.
4-10
[preset] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with
ENTER.
• If the selected input is a COMPUTER signal the IMAGE MENU displays:
4-5
[black level] + ENTER.
Adjust the black level with + ENTER.
4-6
[color] + ENTER.
Select a color (Red, Green, or Bleu) with + ENTER and adjust the level with + ENTER.
4-7
[optimize] + ENTER.
• [clock]: Manual adjustment of the pixel clock.
• [phase]: Manual adjustment of the pixel phase.
4-8
[preset] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with
ENTER.
