APPENDIX A / ANNEXE A
CENTRIX™ & EVENTIX™
PAGE 126
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
CONTROLS COMMANDS / COMMANDES DU MENU CONTRÔLE
ja
TALA
Input number for TALLY1
Rd/Wr
1
8
jb
TALB
Input number for TALLY2.
Rd/Wr
1
8
jc
TALC
Input number for TALLY3.
Rd/Wr
1
8
1 = input #1.
.......
8 = input #8.
JA TAON
TALLY1
status.
Rd
0
1
0 = TALLY1 inactive 1 = TALLY1 active.
JB TBON
TALLY2
status.
Rd
0
1
0 = TALLY2 inactive 1 = TALLY2 active.
JC TCON
TALLY3
status.
Rd
0
1
0 = TALLY3 inactive 1 = TALLY3 active.
QE
EPD
2:2 pull down correction.
Rd/Wr
0
1
0 = off
1 = auto.
ye
EPOS
Erase all memories.
Rd/Wr
0
1
1 = erase all memories (automatic reset).
yd DEMO
Demo
mode.
Rd/Wr
0
1
0 = demo mode inactive.
1 = demo mode active.
yi
EISP
Auto-lock
Rd/Wr
0
1
0 = off
1 = on.
fr BFCR
Red adjustment of the FADE (M).
Rd/Wr
0 255
fb BFCB
Blue adjustment of the FADE (M).
Rd/Wr
0 255
fg BFCG
Green adjustment of the FADE (M).
Rd/Wr
0 255
LF LFAD
Transition (M).
Rd/Wr
0 3
lF lfad
Transition (P).
Rd/Wr
0 3
0 = fade color
1 = frame 1
2 = frame 2
3 = clean cut
fR
bfcr
Red adjustment of the FADE (P).
Rd/Wr
0 255
fB bfcb
Blue adjustment of the FADE (P).
Rd/Wr
0 255
fG bfcg
Green adjustment of the FADE (P).
Rd/Wr
0 255
yF FRAL
FRAME
ALERT
Rd/Wr
0 11
0 = no frame
1 = frame 1
2 = frame 2
3 = black
4 = input 1....
11 = input 8
xI I_
Identification
number.
Rd
0 65535 Values displayed in hexadecimal in the device.
xU VERU
Update
version.
Rd
0 65535 Example: VERU104 = version 1.4
Y
FRES
DEFAULT VALUE.
Rd/Wr
0
1
1 = Default value action (automatic reset).
COMMUNICATION COMMANDS / COMMANDES DE COMMUNICATION
ne
LANE
Communication port selection
Rd/Wr
0
1
0 = RS232
1 = LAN
nr
LANR
Reset of the LAN parameters.
Rd/Wr
0
1
1 = reset.
ns
LANS
Store the LAN parameters.
Rd/Wr
0
1
1 = store.
na ADIP
IP address and port selection (for
modification)
Rd/Wr
0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw IPA_
First byte of the address selected by the
na command.
Rd/Wr
0 255
nx IPB_
Second byte of the address selected by
the na command.
Rd/Wr
0 255
ny IPC_
Third byte of the address selected by
the na command.
Rd/Wr
0 255
nz IPD_
Forth byte of the address selected by
the na command.
Rd/Wr
0 255
np PORT
Number of the port (local or remote)
selected by the na command.
Rd/Wr
0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk NTMK
netmask.
Rd/Wr
0
24
Value = number of bit to 0 (from right).
example: 2
255.255.255.252
3
255.255.255.248
.............
8
255.255.255.0.............
24
255.0.0.0
nt
TCP
protocol selection.
Rd/Wr
0
1
0 = UDP
1 = TCP
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
