CENTRIX™ & EVENTIX™ APPENDIX A / ANNEXE A
PAGE 125
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
FRAME & LOGOS COMMANDS (continued) / COMMANDES DU MENU LOGOS & FRAME (suite)
lM lmod Frame/logo mode. Rd/Wr 0 3
0 = use & assignment mode.
1 = logo recording mode.
2 = frame recording mode.
3 = erasing mode.
lX lsta Status of the logo programmer Rd 0 4
0 = free.
1 = logo/frame in recalling process.
2 = logo/frame in storing process.
3 = output format incompatible with the logo.
4 = logo/frame in erasing process.
lA lpga Logo 1 & frame assignment. Rd/Wr 0 10
lB lpgb Logo 2 & frame assignment. Rd/Wr 0 10
0 = none 1 = frame 1 2 = frame 2
3 = logo 1 4 = logo 2........ 10 = logo 8
lC lcur
• In logo recording mode: Number of
the logo to be store (3 to 10).
• In frame recording mode: Number of
the frame to be store (1 or 2).
• In erase mode: number of the logo to
be erase (0 = erase all).
Rd/Wr 0 10
0 = no logo 1 = frame 1
2 = frame 2 3 = logo 1
4 = logo 2................... 10 = logo 8
lD ldys Display logo (according to PCH) Rd/Wr 0 1 0 = Display OFF 1 = Display ON
lU lhcp Horiz. position of the logo storing area. Rd/Wr 0 255
lu lvcp Vert. position of the logo storing area. Rd/Wr 0 255
lW lhsa Horizontal size of the logo storing area. Rd/Wr 5 255 5 = 3% 255 = 100%
lS lvsa Vertical size of the logo storing area. Rd/Wr 5 255 5 = 3% 255 = 100%
lH lhpa Horizontal position of the logo 1. Rd/Wr 0 255
lh lhpb Horizontal position of the logo 2. Rd/Wr 0 255
lV lvpa Vertical position of the logo 1. Rd/Wr 0 255
lv lvpb Vertical position of the logo 2. Rd/Wr 0 255
lP lpxa Pixels number in a line of the logo 1. Rd 0 65535
lL llna Lines number in a logo 1. Rd 0 65535
These 2 commands allow to calculate the
duration of the storing.
lp lpxb Pixels number in a line of the logo 2. Rd 0 65535
ll llnb Lines number in a logo 2. Rd 0 65535
These 2 commands allow to calculate the
duration of the storing.
lT ltya Logo 1 type. Rd/Wr 0 1
lt ltyb Logo 2 type. Rd/Wr 0 1
0 = frame 1= logo.
lO lofa Output format during the logo1 storing. Rd 0 11
lo lofb Output format during the logo2 storing. Rd 0 11
Identical as F command.
lR lsto
• In recording mode: frame/logo storing.
• In erase mode: frame/logo erasing.
Rd 0 1 1 = STORE or ERASE (automatic reset).
lr labt Stop the frame storing. Rd/Wr 0 1 1 = stop the frame storing (automatic reset).
PREVIEW / OUTPUT 2
lZ LPTP Logo transparency Rd/Wr 0 15 0 = mini 15 = maxi
LE LLEV Luma key level. Rd/Wr 0 255
lE LEMP
Status of the frame/logo memories.
(according to lcur)
Rd 0 1
0 = logo/frame memorized.
1 = empty memory.
Lb LBKC Background color. Rd/Wr 0 7
Ld LLD Fade logo duration (0.01 second step). Rd/Wr 15 255 15 = 0.15 second 255 = 2.5 seconds
Lf LFD Fade frame duration (0.1 second step). Rd/Wr 5 50 5 = 0.1 second 50 = 5 seconds
NOTE: To store a logo from the PREVIEW display you should:
c Select the logo recording mode with the lM command (1lM).
d Adjust the position and size of the logo storing area with the lU, lu, lH and lh commands.
e Adjust the luma key level (with LE command) and the background color (with Lb command).
f Select a logo memory with the lC command and make a store with lR command (1lR).
To store a frame from the PREVIEW display you should:
c Select the frame recording mode with the lM command (2lM), and make a store with the lR command (1lR).
NOTE: To assign a logo/frame to an input on the PREVIEW display you should:
c Select the assignment mode with the lM command (0lM).
d Select a stored logo/frame with lA, or lB commands.
e Adjust the horizontal & vertical position of the logo with the lH, lh, lV & lv commands.
