APPENDIX A / ANNEXE A
CENTRIX™ & EVENTIX™
PAGE 128
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
VIDEO OUTPUTS COMMANDS (OPT-iX-SDTVD1 option) / COMMANDES DE LA SORTIE VIDÉO (option OPT-iX-SDTVD1)
kR SREQ
Input reference for the frame rate of the
video output.
Rd/Wr
0 8
kT
SSTA
Status of the frame rate reference.
Rd
0 8
0 = internal rate
1= input #1................... 8 = input #8.
kM
SFAM
Standard input signal of the reference. Rd
0
29 Identical as IF command.
kQ SFRQ
Frame rate of the input reference (in
hundredth of Hz)
Rd
0 65535
kC
SVCR
Input stability.
Rd/Wr
0
1
0 = DVD
1 = VCR
kJ STRK
Color
tracking
Rd/Wr
0 255
kA SAFK
Anti-flicker
level.
Rd/Wr
0
7
kO SOVR
Under/overscan
mode.
Rd/Wr
0
1
0 = underscan
1 = overscan
kD
SSTD
Output video standard
Rd/Wr
0
2
0 = NTSC
1 = PAL
2 = NTSC J
kD
SSTD
Output video standard
Rd/Wr
0
6
0 = NTSC / 720p 59.94 1 = PAL / 720p 60
2 = NTSC J / 1035i 59.94
3 = 1035i 60
4 = 1080i 50
5 = 1080i 59.94
6 = 1080i 60
kK
SK_
"SK" firmware version.
Rd
0 65535
kS
SS_
"SS" firmware version.
Rd
0 65535
kV
SV_
"SV" firmware version.
Rd
0 65535
kF
SF_
"SF" firmware version.
Rd
0 65535
kW SHPO
Horizontal
position.
Rd/Wr
0
255
kX SVPO
Vertical
position.
Rd/Wr
0
255
kY SHSZ
Horizontal
size.
Rd/Wr
0
255
kZ SVSZ
Vertical
position.
Rd/Wr
0
255
SOFT-EDGE BLENDING COMMANDS (CBD-UP option) / COMMANDES DE SOFT-EDGE BLENDING (option CBD-UP)
eS EDGS
Covering
size.
Rd/Wr
1
eA
EDGA
Device position in the screen.
Rd/Wr
1 255
bits 0 to 3: device position.
bits 4 to 7: number of devices.
eP
EFA
Effect position in the screen.
bits 0 to 3: device position.
bits 4 to 7: number of devices.
eC
PEDG
Extended input selection (works with
PC command).
Rd/Wr
1
1
0 = not extended
1 = extended.
eT EDGT
Softedge
type.
Rd/Wr
1 1
0 = horizontal
1 = vertical.
eV EDGV
Softedge
activation.
Rd/Wr
1 1
0 = inactive
1 = active.
LK
LUTC
LUT loading control.
Rd/Wr
1 10
1 = reset the LUT.
3 = LUT loading (softedge curve).
5 = linear softedge.
9 = softedge writing LUT selection.
10 = softedge displayed LUT selection.
K
L
-Values to set in the LUT (if LUTC=3)
-Softedge curve selection (if LUTC=9
or 10).
Rd/Wr
0 255
if LUTC = 3: 0 to 255.
if LUTC = 9 or 10: 0 or 1.
eJ
EDGR
Black level: red adjustment.
Rd/Wr
0 7
eK
EDGG
Black level: green adjustment.
Rd/Wr
0 7
eL
EDGB
Black level: bleu adjustment.
Rd/Wr
0 7
eH
EDGH
Black area: right adjustment
Rd/Wr
0 2047
el
EDGI
Black area: left adjustment
Rd/Wr
0 2047
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
