EN
4
WALL OR UNDER COUNTER INSTALLATION, SINGLE OVEN
A
B
C
F
E
B
A
C
E
D
Secure oven to cabinet using the screws provided.
Screws should be inserted through the mounting holes in the positions
indicated in the frame (open door to see frame and mounting holes).
Do not over tighten screws.
Electrical supply junction box
Electrical supply junction box
WALL INSTALLATION, DOUBLE OVEN
A
B
C
F
E
Secure oven to cabinet using the screws provided.
Screws should be inserted through the mounting holes in the positions
indicated in the frame (open door to see frame and mounting holes).
Do not over tighten screws.
Electrical supply junction box
Installation Instructions
