EN
8
Connecting to 208 volt circuit
This option is provided for areas where standard 240 Volt
service is not available. This option must be accessed with
the oven connected to power source, and using the following
sequence:
a) Press the SET key and select the option by means of the
arrow and confi rm with the START key.
SETUP
SERVICE
b) From the “SYSTEM” menu select the “MAIN VOLTAGE”
option and confi rm again with the START key.
EVENT LOGS
MAIN VOLTAGE
SYSTEM
DEMO
OM 15
c) By means of the arrow, select the “208V” option and
confi rm with the START .
MAIN VOLTAGE
240
ADVANCED
The voltage setting is stored and kept even after a long
power-off.
WARNING
ELECTRICAL SHOCK HAZARD
• The electrical power to the oven branch circuit must be
shut off while line connections are being made.
• Do not use an extension cord with this appliance.
• Electrical ground is required on this appliance. The free
end of the green wire (the ground wire) must be connected
to a suitable ground. This wire must remain grounded to
the oven.
• If cold water pipe is interrupted by plastic, non metallic
gaskets, union connections or other insulating materials,
DO NOT use for grounding.
• DO NOT ground to a gas pipe.
• DO NOT have a fuse in the NEUTRAL or GROUNDING
circuit. A fuse in the NEUTRAL or GROUNDING circuit
could result in an electrical shock.
• Check with a qualifi ed electrician if you are in doubt as to
whether the appliance is properly grounded.
• Failure to follow these instructions could result in serious
injury or death.
CAUTION
Do not repair or replace any part of the appliance unless
specifi cally recommended in the manual. All other servicing
should be done by a qualifi ed technician. This may reduce
the risk of personal injury and damage to the oven.
Never modify or alter the construction of the appliance by
removing panels, wire covers, screws, or any other part of
the product.
Installation Instructions
