EN
2
Introduction
Please read these instructions COMPLETELY AND CAREFULLY .
They will save you time and effort and help to ensure optimum
oven performance.
Be sure to observe all WARNINGS. These installation
instructions are intended for use by a qualified installer.
In addition to these instructions, the oven shall be installed:
• In the United States, in accordance with the National Electric
Code/State and Municipal codes and/or local codes.
• In Canada, in accordance with Canadian Electric Code
C22.1-latest edition/Provincial and Municipal codes and/
or local codes.
These shall be carefully followed at all times.
NOTE : If installing your oven in canada please check to make
sure that you have a model with the us and canadian
listing
Mark, as shown above:
Mark as shown above means the oven complies with both US
and CANADIAN Standards.
Tools you will need
The following tools are needed to install your new oven:
• Tape measure and straightedge or ruler
• Pencil
• Phillips screwdriver
• Level
• Wire cutters and wire stripper
• Hand or saber saw
• 1” (2,5cm) Hole saw
• Drill and drill bit
• Safety gloves and goggles
• Volt meter (0-250VAC)
Packaging
Remove all tape and packaging before using the oven.
Destroy the packaging after unpacking the oven following the
rules in force in your town. Never allow children to play with
packaging material.
Power requirements
The oven must be supplied with the proper voltage and
frequency. The oven is manufactured to be connected to a
three-wire or four-wire, single phase, 120/240 Volt, 60 Hz AC
electrical supply on a separate circuit fused on both sides of the
line. If a 120/208 Volt circuit must be used, see Connecting to
120/208 Volt Circuit, in this manual.
A circuit breaker or time delay fuse, sized not to exceed
the circuit rating of the appliance specified on the rating
plate located on the frame behind the door of the oven is
recommended (see figure at page 4).
The oven must be supplied with copper or alumimum wires.
If aluminum wire is provided to connect oven to branch circuit,
UL listed connectors for joining copper and aluminum must be
used. Follow instructions provided with connectors.
It is recommended that you have the electrical wiring and hook-
up of your oven performed by a qualified electrician.
After installation is complete have the electrician show you
where the main disconnect is and which of the circuit breakers/
fuses are for the oven.
Choosing oven location
Carefully select the location where the oven will be placed.
The oven should be located for convenient use in the kitchen,
but away from strong drafts.
Strong drafts may be caused by open doors or windows, or
by heating and/or air conditioning vents or fans. Make sure
that electrical power can be provided to the location selected.
WARNING
If installed at an ambient temperature of less than 37°F (3°C),
the oven may present error F*0117. When the oven reaches
a higher ambient temperature, the error will disappear.
Steps for installation
The following pages provide the necessary information for
proper installation of the oven and are arranged as follows:
• Technical Data
• Installation Cutout Dimensions, Required Clearances and
Mounting instructions for:
- Under counter Installation, Single Oven
- Wall Installation, Single Oven
- Wall Installation, Double Oven
• Electrical Supply and Wiring Requirements, Programming
required if connecting to 120/208 Volt Circuit. Electrical
Connections for 3-wire or 4-wire Branch Circuit.
• Final Checklist
Installation Instructions
