EN
29
WARNING
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or death.
Introduction
Please read these instruction COMPLETELY AND CAREFULLY.
They will save you time and effort and help to ensure
optimum oven performance.
Be sure to observe all WARNINGS.
These installations are intended for use by a qualified
installer.
In addition to these instructions, the oven shall be installed:
• In the United States, in accordance with the National
Electric Code/State and Municipal codes and/or local
codes.
• In Canada, in accordance with Canadian Electric Code
C22.1- latest edition/Provincial and Municipal codes
and/or local codes.
These shall be carefully followed at all times.
NOTE: IF INSTALLING YOUR OVEN IN CANADA PLEASE
CHECK TO MAKE SURE THAT YOU HAVE A
MODEL WITH THE CANADIAN LISTING
MARK, AS SHOWN ABOVE:
Mark as shown above means the oven complies with both
US and CANADIAN Standards.
Tools you will need
The following tools are needed to install your new oven:
• Tape measure and straight edge or ruler
• Pencil
• Phillips screwdriver
• Level
• Wire cutters and wire stripper
• Hand or saber saw
• 1” (2.5 cm) Hole saw
• Drill and drill bit
• Safety gloves and goggles
• Volt meter (0-250VAC)
Packaging
Remove all tape and packaging before using the oven.
Destroy the packaging after unpacking the oven following
the rules in force in your town. Never allow children to play
with packaging material.
Power requirements
The oven must be supplied with the proper voltage and
frequency. The oven is manufactured to be connected to a
three-wire, single phase, 120/240V, 60 Hz AC electrical
supply on a separate circuit fused in both sides of the line.
A circuit breaker or time delay fuse sized not to exceed
the circuit rating of the appliance specified on the rating
plate located on the frame behind the door of the oven is
recommended.
The oven must be supplied with copper or aluminum wires.
If aluminum wire is provided to connect oven to branch
circuit, UL listed connectors for joining copper and aluminum
must be used. Follow instructions provided with connectors.
If is recommended that you have the electrical wiring and
hook-up of your oven performed by a qualified electrician.
After installation is complete have the electrician show
you where the main disconnect is and which of the circuit
breakers/fuses are for the oven.
Choosing oven location
Carefully select the location where the oven will be placed.
The oven should be located for convenient use in the kitchen,
but away from strong drafts.
Strong drafts may be caused by open doors or windows,
or by heating and/or air conditioning vents or fans. Make
sure that electrical power can be provided to the location
selected.
Steps for installation
The following pages provided the necessary information for
proper installation of the oven and are arranged as follows:
• Technical Data
• Installation Cutout Dimensions, Required Clearances and
Mounting instructions for:
- Under counter installation, Single Ove
- all installation, Single Oven
TECHNICAL DATA
Power supply 120-240 V~, 60 H z 3400 W
Power supply 120-208 V~, 60Hz 2700 W
Microwave power 900 W
Grill 1500 W
Convection 1500 W
Microwave frequency 2450 MHz
