14 - For the Installer
Cutout
The oven can be installed under a work top or in a cooking column. Figure shows the installation dimensions.
Make sure that surrounding materials are heat resistant. Align the oven centrally with respect to the side walls of the furniture
surrounding it and fix it in place with the screws and Allen screws provided.
24” (60 cm)
min
18-1/8”
(460)
2”
(50) 20"
(510)
22”
(560)
17-1/8”
(436)
21”
(533)
23-3/8”
(594)
21-1/4”
(540)
min 17-3/4”
(450)
2”
(50)
17-7/8”
(455)
20"
(510)
22”
(560)
21-1/4”
(540)
18-1/8”
(460)
17-1/8”
(436)
21”
(533)
17-7/8”
(455)
23-3/8”
(594)
min. 1/8” (3) Flat aesthetics
min. 1-1/8” (30) Protruding aesthetics
Note: when sliding the oven into
the opening be sure to
remove the temporary
handles on each side to
prevent potential vibratory
noise.
30” (75 cm)
min 18-7/8”
(480)
2”
(50) 21-1/2"
(546)
25-1/4”
(641)
17-1/8”
(436)
21”
(533)
29-13/16”
(758)
21-1/4”
(540)
min 17-3/4”
(450)
2”
(50)
18-5/8"
(473)
21-1/2 "
(546)
25-1/4”
(641)
21-1/4”
(540)
18-7/8”
(480)
17-1/8”
(436)
21”
(533)
18-5/8"
(473)
29-13/16”
(758)
min. 1/8” (3) Flat aesthetics
min. 1-1/8” (30) Protruding aesthetics
Note: when sliding the oven into
the opening be sure to
remove the temporary
handles on each side to
prevent potential vibratory
noise.
