EN
12
Key
This cooking surface allows setting a keypad lock using the
lock button (5) . It may be useful to lock the keypad during
operation, for example for cleaning the control area or, in any
case, if you do not want to change any settings. The On/Off
button (1) remains functional.
Pause
This cooking surface allows setting a pause (6) during cooking
(which is useful, for example, when answering a phone call).
When this function is pressed, an LED lights above the button
and the symbol “II” is displayed in all the cooking areas and
the cooking settings and timers are frozen for a maximum of
10 minutes, after which the cooking surface turns off.
Deactivating Pause
Once activated, the function can be deactivated by pressing
the pause button (6) again. The LED for the pause setting turns
off and, within 10 seconds, you must slide your finger along
the cursor below the illuminated area (from left to right). This
allows the surface to resume cooking and the timer starts from
the same point at which it was stopped.
Timer function
NOTE: the timer is only intended as an acoustic advisor that
recalls the attention of the user.
Timers have no effect on the heating elements. Cooking
zones must always be stopped manually by touching
the corresponding [OFF] key.
There are two versions of the timer function:
• An independent timer from 1 to 59 minutes: it beeps when
the time has run out. This function is always available and is
indicated by the clock symbol (24) which is located between
the - and + buttons (the symbol may be less bright if another
cooking area timer has a remaining time that is less than that
set on the independent timer).
• A timer from 1 to 59 minutes for each cooking area: it
beeps when the time has run out. The cooking areas can be
programmed independently (the symbol may be less bright if
another cooking area timer has a remaining time that is less
than that set on the independent timer).
The type of timer activated is shown in the dedicated displays.
The timer with the least time is highlighted and the related clock
icon is brighter (13-24) . The other timer settings are still active
and running, but the clock icon (13-24) will be less bright.
Another icon with the word “min” (23) appears when you set
times longer than 10 minutes. For example 0.11 indicates 0
hours and 11 minutes. The separator dot (21) flashes when
the timer is running, while the dot is static while the timer is
selected and thus modifiable.
Independent timer
• If the touch display is on, the independent timer can be
used by simultaneously pressing the + and - buttons. If all
the cooking areas are in position “0”, this is the only timer
available. The clock icon (24) will turn on and the display
will show “0.00”. If you do not select any button, the timer
deactivates within 5 seconds.
• The time setting (0-1hour.59min) can be changed in
increments of one minute with the + button from 0 to 99.
• Holding down the + or - button dynamically increases the
rate of change up to a maximum value, without beeps.
• If the + (or -) button is released, the rate of increase (decrease)
starts again from the initial value.
• The timer can be set by either continuously pressing the +
or - buttons or by pressing successively (with beeps).
After the timer is set, it begins to count down. The expiry of
the time is signalled by a beep or by the flashing of the timer
display, which will show “00”.
Turning off/changing the timer
• The timer can be changed or turned off at any time by turning
on the touch display again, if no cooking area is on, and
pressing the + and - buttons simultaneously to select the timer.
At this point, set it to “0” by pressing the - button, to turn it
off, or by pressing the + button to increase the time setting.
• The independent timer remains active even when the On/
Off button is pressed
Programming the timer for the cooking
areas
By turning on the touch display, you can program an
independent timer for each cooking area.
• At least one cooking area must be on and set to a certain
level.
• By pressing the + and - buttons simultaneously, you can
set a countdown for turning off the cooking area. There
are illuminated clock icons (13) next to the display of the
cooking area. To set the timer on a cooking area when there
are more than one cooking area on, you must press the +
and - buttons simultaneously. You will note that the clock icon
will light and move to successive cooking areas each time
you simultaneously press the + and - buttons.
• When the timer of the cooking area is selected, the related
clock icon near the display becomes brighter (13) . The
timers programmed for each cooking zone remain active.
• Other functions of the timer are the same as the independent
timer. To increase the time, use the + (plus) button.
• The beeping and flashing of the display stops:
a- Automatically after 2 minutes.
b- When you press the + or - buttons, the timer display turns off.
