DIMENSIONS
COMMERCIAL-STYLE RANGES
IMPORTANT:
Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information.
Refer to the Installation Guide before
selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All KitchenAid
®
appliances are appropriately UL, CUL or CSA approved.
5 of 30
PRODUCT DIMENSIONS
MODEL #
30" (76.2 cm) RANGES
DUAL-FUEL/GAS
KFDC500J/KFGC500J
36" (91.4 cm) RANGES
DUAL-FUEL/GAS
KFDC506J/KFGC506J
48" (121.9 cm) RANGES
DUAL-FUEL/GAS
KFDC558J/KFGC558J
Unit of Measurement
in
cm
in
cm
in
cm
Grates Top Height (A)
37
3
⁄
16
94.5
37
3
⁄
16
94.5
37
3
⁄
16
94.5
Cooking Surface Top Height (B)
36
91.4
36
91.4
36
91.4
Door Top Height (C)
27
7
⁄
8
70.8
27
7
⁄
8
70.8
27
7
⁄
8
70.8
Handle Top Height (D)
27
1
⁄
8
68.9
27
1
⁄
8
68.9
27
1
⁄
8
68.9
Toe-Kick Height (E)
6
5
⁄
8
16.9
6
5
⁄
8
16.9
6
5
⁄
8
16.9
OTHER DIMENSIONS
Maximum Feet
Extension Height*
1
1
⁄
2
3.8
1
1
⁄
2
3.8
1
1
⁄
2
3.8
* IMPORTANT:
Minimum height dimensions are at the lowest point of the height adjustment range.
When the leveling legs are fully extended, all heights have 1
1
⁄
2
" (3.8 cm) of added height.
SIDE VIEW
.
A
E
D
C
B
