Built-In Series Overview
To access more information on:
• Cut out dimensions
• Cleaning
• Maintenance
• Warranty
Visit https://www.napoleon.com for the complete overview of the Napoleon Built-In Series.
MAIN
BIB10RT / BI10RT
Propane #64
Natural gas #55
BIB10IR
Propane #64
Natural gas 1.27mm
BIB12RT / BI12RT
Propane 1.2mm
Natural gas 1.7mm
BIB18RT
Propane 1.2mm
Natural gas 1.7mm
BIB18IR
Propane 1.15mm
Natural gas #52
BIB18PB
(outer ring) Propane 1.75mm
Natural gas 2.4mm
BIB18PB
(inner ring) Propane 1.4mm
Natural gas 2.05mm
Orifice Sizes
The following table lists the orifice size corresponding to each burner.
Use this as reference when servicing the grill.
(GROSS)
HEAT INPUT
(TOTAL)
GAS USAGE
(TOTAL)
MAIN MAIN
BIB 10 RT 3.5kW 255 g/hr
BIB 10 IR 3.5 kW 255 g/hr
BIB 12 RT 10 kW 728 g/hr
BIB 18 IR 10 kW 728 g/hr
BI 12 RT 10 kW 728 g/hr
BI 10 RT 3.0 kW 218 g/hr
