napoleon.com | 1 N415-0649 - BIG38RB - 38" BUILT-IN 700 SERIES - TECHNICAL SHEET | REVISED: 2020.08.17
ENG
38" BUILT-IN 700 SERIES
WITH REAR BURNER AND OPTIONAL ZERO CLEARANCE LINER
MODEL: BIG38RB WITH BI-4223-ZCL
SERIES: 700
FINISH: 304 STAINLESS STEEL WITH BRUSHED TRIM
INTRODUCTION
Napoleon's Built-In 700 Series 38-inch Gas Grill with Rear Infrared Burner is a seamless addition to your custom made outdoor grilling area. Precisely control the temperature for
searing, smoking, and rotisserie grilling, the ACCU-PROBE
™ temperature gauge knows where all of the sweet spots are. Ignite the grill one-handed using the NIGHTLIGHT ™ control
knobs which provide ambiance and safety, glowing a glorious blue and changing to red when burners are in use. The JETFIRE ™ ignition system ignites instantly with a jet of flame
and cross lights with the other burners. Marine-grade stainless construction ensures stylish longevity and unparalleled performance. Thick, 9.5mm stainless steel cooking grids are
virtually maintenance-free and provide
ICONIC WAVE ™ sear marks. With integrated trim and longer electrical wiring, the Built-In 700 Series 38-inch Gas Grill has been designed
specifically for ease of installation, design, and functionality without restricting installation.
DIMENSIONS INCHES MM
Cut-out height of cavity for appliance (min) 10 1/4 260
Cut-out width of cavity for appliance (min - max) 36 – 38 914 - 965
Cut-out depth of cavity for appliance (min - max) 19 3/8 - 19 3/4 492 - 502
Cut-out height of cavity for liner 11 1/4 286
Cut-out width of cavity for liner 42 1067
Cut-out depth of cavity for liner 22 1/4 565
SPECIFICATIONS INCHES CM
Total cooking area (squared) 945 6112
Primary cooking area (squared) 630 4080
Warming rack area (squared) 315 2032
Primary cooking area depth 17 7/8 45.4
Primary cooking area width 35 3/8 89.9
GAS REQUIREMENTS
Type of flare adaptor 1/2" 45º flare
Gas requirements – Propane or Natural Gas LPG / NAT
Operational pressure (WATER COLUMN) 11" / 7"
Supply pressure (WATER COLUMN) 11" / 7"
RATINGS
Number of main tube burners 5
Main burner BTU’s 12,000
Number of rear burners 1
Rear burner BTU’s 18,000
Total BTU’s 78,000
Rotisserie motor weight capacity 25lbs
POWER REQUIREMENTS
Knob lighting power supply GFCI: 110 - 120 VAC 15A 50 – 60 HZ
Rotisserie power supply GFCI: 110 - 120 VAC 15A 50 – 60 HZ
