5
Check Your Vent System for Good
Airflow
WARNING
Fire Hazard
Use a heavy metal vent.
Do not use a plastic vent.
Do not use a metal foil vent.
Failure to follow these instructions can result in death or
fire.
Good Airflow
Along with heat, dryers require good airflow to efficiently dry
laundry. Proper venting will reduce your drying times and improve
your energy savings. See Installation Instructions.
The venting system attached to the dryer plays a big role in good
airflow. Blocked or crushed vents as well as improper venting
installation will reduce air flow and dryer performance.
Service calls caused by improper venting are not covered by the
warranty and will be paid by the customer, regardless of who
installed the dryer. To clean or repair venting, contact a venting
specialist.
Maintain Good Airflow
� Cleaning your lint screen before each load.
� Replace plastic or foil vent material with 4" (102 mm) diameter
heavy, rigid vent material.
� Use the shortest length of vent possible.
� Use no more than four 90° elbows in a vent system; each bend
and curve reduces airflow.
� Remove lint and debris from the exhaust hood.
� Remove lint from the entire length of the vent system at least
every 2 years. When cleaning is complete, be sure to follow
the Installation Instructions for final product check.
� Clear away items from the front of the dryer.
Nonuse, Storage, and Moving Care
Nonuse or Storage Care
If you will be on vacation or not using your dryer for an extended
period of time, you should:
1. Unplug dryer or disconnect power.
2. Clean lint screen. See “Cleaning the Lint Screen.”
Moving Care
For power supply cord-connected dryers:
1. Unplug the power supply cord.
2. Make sure leveling legs are secure in dryer base.
3. Use tape to secure dryer door.
Reinstalling the Dryer
Follow the Installation Instructions to locate, level, and connect the
dryer.
INSTALLATION INSTRUCTIONS
REQUIREMENTS
Tools and Parts
NOTE: Install the clothes dryer according to the manufacturer’s
instructions and local codes.
Gather required tools and parts before starting installation. Read
and follow the instructions provided with any tools listed here.
Tools Needed for All Installations:
Flat-blade
screwdriver
Level
Caulking gun and
compound (for
installing new
exhaust vent)
Adjustable wrench
that opens to 1” (25
mm) or hex-head
socket wrench Tin snips (new vent
installations) Vent Clamps
Parts Supplied:
Parts package is located in dryer drum. Check that all parts are
included.
Leveling legs (4) Cycle control knob Start button
NOTE: Do not use leveling legs supplied with dryer if installing
with a pedestal or stack kit.
Alternate Parts (not supplied with dryer):
Portable assembly kit
Your installation may require
additional parts. To order, please
refer to the Quick Start Guide. You
may also contact the dealer from
whom you purchased your dryer.
� Mobile home installations
require metal exhaust system
hardware.
� For portable installations you will
need an optional portable
assembly kit including 4 casters,
power cord brackets and screws.
