Whirlpool 29 Inch Electric Dryer Dryer Cycle Guide - Manuel (Page 2)

2
Jackets, comforters,
pillows. BULKY ITEMS High
Medium
Low
Extra Low
Wrinkle Shield™
Mute Cycle
Signal
Use for drying large, bulky items; do not
overfill dryer drum. Partway through the
cycle, the signal will sound to indicate
when it is time to rearrange items for
optimal drying.
Work clothes, casual
wear, mixed cottons,
sheets, corduroys. LESS DRY High
Medium
Low
Extra Low
Wrinkle Shield™
Mute Cycle
Signal
Static Reduce
Uses Medium heat as default to dry loads
of Mixed Fabrics and items, with slightly
lower temperatures than Normal Cycle and
tuned to achieve "Less Dry" results.
Large loads of jeans,
towels and heavyweight
items. TOWELS High
Medium
Low
Extra Low
Wrinkle Shield™
Mute Cycle
Signal
Static Reduce
This is a long cycle with High heat as
default. This cycle is not recommended for
all fabrics. Use for large loads of
heavyweight fabrics.
On steam models, you may select the “Static Reduce” setting. The dryer will automatically tumble, pause, and introduce a small amount
of moisture into the load to help reduce static. This option adds approximately 3 minutes to the total cycle time.
Steam Refresh Cycle (on some models)
Steam cycles are designed for use with dry loads to loosen wrinkles, reduce odors, and refresh fabrics.
Not all cycles and settings are available on all models. Settings and options shown in bold are default settings for that cycle.
Items to Refresh: Cycle: Temperature: Available
Options: Description:
Shirts, blouses and
slacks STEAM REFRESH
High
Medium
Wrinkle Shield™
Mute Cycle
Signal
Use to smooth out wrinkles and reduce
odors from loads left in the dryer too long.
Do not add dryer sheets.
Timed Cycles
In these cycles, you can specify the drying time. Time options available are 15, 30, 60 and 90 minutes. If settings are changed, the new
settings will be remembered (except on Quick Dry). If there is a power failure, settings will return to the default. Not all features and cycles
are available on all models. Not all settings and options are available on each cycle.
Items to Dry: Cycle: Temperature: Available
Options: Description:
Any Load. TIMED DRY
High
Low
Extra Low
Wrinkle Shield™
Mute Cycle
Signal
Use to dry items to a damp level for items
that do not require an entire drying cycle.
Select a drying temperature based on the
type of fabrics in your load. If you are
unsure of the temperature to select for a
load, select the lower setting rather than
the higher setting.
Small loads and
sportswear. QUICK DRY
High
Low
Extra Low
Wrinkle Shield™
Mute Cycle
Signal
For small loads of 3-4 items.
Foam, rubber, plastic or
heat sensitive fabrics. AIR ONLY N/A Wrinkle Shield™
Mute Cycle
Signal
Uses unheated air to dry heat-sensitive
items
Medium
Medium
