7
Install the Microwave Oven
1. Remove any contents of the microwave oven.
2. Using 2 or more people, lift microwave oven, and place it onto
the L-brackets. Gently slide the microwave oven back against
the rear wall.
3. Check level of microwave oven.
4. Start the leveling screws in the front and back holes of the
L-bracket bases, and adjust the level using the hex key, if
necessary.
5. Place a washer on each 16 mm round-head bolt, then install
each bolt through the L-bracket base slot, into the mounting
hole in the bottom of the microwave oven. Do not overtighten.
Install Damper Assembly
1. Insert damper assembly through the upper cabinet cutout,
and orient it so that the 3 mounting holes are toward the back
of the microwave oven.
2. Secure the damper assembly to the upper component
housing with five 9.5 mm metal screws.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
microwave oven.
Failure to do so can result in back or other injury.
A. Damper assembly
B. Upper cabinet cutout
C. 9.5 mm metal screws (5)
A B C
