Cybex 750AT Arc Trainer - Manuel (Page 58)

Technical Specifications
A-2
Cybex Arc Trainer 750A/750AT Owner’s Manual
750AT Technical Specifications
Classification: S (Studio)
Accuracy: A
Assembled Length:
76.25” (194 cm)
Assembled Width: 36.28” (92 cm)
Height: 39.79”(101 cm)
Weight of Product: 404 lbs. (183 kg.)
Shipping Weight: 429 lbs. (195 kg.)
Incline Levels: 0-20
Resistance Levels: 101 (Represented by 0-100% in increments of 1).
Stride Length: 24” (61 cm) fixed length.
Programs: Quick Start plus Manual, 8 Factory Programs, Heartrate Control, Constant Power,
Power Training, Fitness Test, and ability to store 9 custom programs.
Console Features: Upper console: Large Bar Graph Matrix for displaying program profiles, 16 character
dot matrix area for display and scrolling text, a multi-color backlit heart for
conveying heartrate range. The Text Display area can show Cal/Hr, Distance, Strides
per Minute, Calories, Watts, METs and BPM.
Lower Console: Two numeric displays for incline, time, resistance and level.Heart
Rate Features: Built-in wireless heart rate receiver (transmitter not included) and contact
heart rate monitoring.
Frame Colors: Standard: White texture, black texture, metaltone gold, black chrome, platinum
sparkle.
Custom: Unlimited colors available.
Resistance Range: 0-900 watt.
Maximum User Weight: 400 lbs. (181 kg).
Power Rating:
Self powered or 100 - 240 VAC~, 50/60 Hz, 1.8A, 1-phase.
Options: Cybex Personal Entertainment Module and optional AC Power Adapter
36.28”
(92 cm)
76.25” (194 cm)
