TRIPLIX™ (TRC8022) Chapter 5 : LCD SCREEN DESCRIPTION (continued)
PAGE 17
5-5. LCD FUNCTIONS DESCRIPTION (continued)
5 [LOGOS/FRAME] + ENTER
5-1 [use logo/frame] + ENTER.
Select an item with  + ENTER.
5-1-1 [display] + ENTER.
This function allows to display ON or OFF the assigned logos of the displayed input. Select an input and
press ENTER to display ON or OFF.
NOTE: To display a logo or a frame, the output format should be the same that the output format used
during the storing.
5-1-2 [assignment] + ENTER.
This function allows assigning the stored frame and the logos to the inputs of the device (up to 2 logos at
the same time).
c Select MAIN or PREVIEW displayed input with  + ENTER.
d Select the frame index or the logo index 1 or the logo index 2 with  + ENTER.
e Then select a logo, a frame or none with  + ENTER.
f Adjust the logo position with H & V position functions.
NOTE: To assign the same logo to all inputs, select ALL in the step c.
5-1-3 [fade duration] + ENTER.
This function allows adjusting the fade duration of the logo when you display ON or OFF a logo. Adjust
the duration with  and validate with ENTER.
5-2 [record logo] + ENTER.
This mode allows storing up to 8 logos in order to incrust them into the displayed image (up to 2 logos at a same
time). Select an item with  + ENTER.
5-2-1 [size] + ENTER.
Adjust the size of the logo area with H & V. Validate with + ENTER.
5-2-2 [position] + ENTER.
Adjust the position of the logo area with H & V. Validate with + ENTER.
5-2-3 [luma key level] + ENTER.
This function allows to "erasing" the darkest portions of your logo area in order to make special logo
contour. Adjust the luma key level with  + ENTER.
5-2-4 [back. color] + ENTER.
This function allows coloring the "erased portions" of the logo when using the luma key. Select a level
with  + ENTER.
5-2-5 [store] + ENTER.
This function allows storing the logo into one of the 8 logo memories. Select a logo memory with  +
ENTER. The memorization will take few seconds.
