Chapter 2 : STARTING (continued)
iX Mate™
PAGE 8
g ANALOG CHANNELS:
For each channel:
- Connect your source (video or computer) to the ANALOG #1 or 2 IN connector.
- Connect all your display devices or iX devices to the ANALOG OUT connectors using output 1 in priority.
- Turn ON your display devices and your input sources.
ANAL
OG #
1
ANALOG # 2
MODEL: XM513
IN
DVI-D
1
2
5
5
5
5
5
5
5
5
• HD15 pin assignment:
SIGNAL COMPUTER (analog)
VIDEO RGB/S
SD-YUV & HD-YUV
S.VIDEO (Y/C)
COMPOSITE VIDEO
PIN 1
RED.
RED.
Cr / Pr. C
(chrominance).
PIN 2
GREEN.
GREEN.
Y.
Y (luminance).
VIDEO (NTSC, PAL...)
PIN 3
BLUE.
BLUE.
Cb / Pb.
PIN 6
RED return.
RED return.
Cr / Pr return.
C return.
PIN 7
GREEN return.
GREEN return.
Y return.
Y return.
return.
PIN 8
BLUE return.
BLUE return.
Cb / Pb return.
PIN 10
GND.
GND.
PIN 13
H sync or C sync (S).
C sync (S).
PIN 14
V sync.
HD15 female connector of the device.
5
6
1
15
10
11
