iX Mate™
PAGE 10
Chapter 4 : TECHNICAL SPECIFICATIONS
• DVI channel
Connectors: 4 x DVI-I female.
Resolution: Up to 1600x1200 @ 60z - 1920x1200 @ 60Hz Red. Blanking.
Support HDTV formats (1080i/p, 720p)
Rate: DVI-D TMDS Single Link-165 MHz re-clocked.
Other: DDC2 loopthrough on output 1.
• SD/HD-SDI channels
Connectors: 4 x BNC female.
Format: TV 525i, 625i - HDTV 1080i/p/sf, 720p
Rate: Digital YUV - 4:2:2- 10 bits
SD-SDI: 270 MHz / HD-SDI: 1.5 GHz
Equalized & re-clocked.
• ANALOG channels
Connectors: 4 x HD15 female.
Format: YUV, RGBHV, RGBS, RGsB, S.VIDEO, Composite Video, HD-YUV & HD-RGB.
Line frequency: From 15 kHz to 130 kHz.
Frame frequency: From 24 Hz to 130 Hz.
Bandwidth: 400 MHz (-3dB).
Signals: RGB/YUV: 0.7 Vp/p up to 1Vp/p.
H & V sync: TTL
2 & 3 levels sync (HD) compatible.
Other: DDC2 loopthrough on output 1.
• ENVIRONMENTAL
Power supply: 100 VAC to 240 VAC; 50-60 Hz; 30 watts, internal, auto-switchable.
Storage Temperature: -25 °C to +85 °C (-13 °F to +185 °F).
Operating temperature: 0 °C to 50 °C (32 °F to 122 °F).
Maximum ambient operating temperature: < 40 °C (< 104 °F).
Hygrometry: 10% to 80% (without condensation).
Dimensions: 1U, 19" Rack Mount compatible.
W 482 x D 190 x H 44 mm.
W 19" x D 7.5" x H 1.74".
Weight: 2.5 kg / 5.5 lbs.
