Whirlpool 30 Inch Combination Smart Wall Oven Control Guide - Manuel (Page 4)

4
Tools Available Selections
Control Lock The Control Lock shuts down the
control panel keypads to avoid
unintended use of the oven(s). The
Control Lock will remain set after a
power failure, if set before the power
failure occurs. When the control is
locked, only the Oven/Microwave
Power, Tools, and Oven Light
keypads will function.
The Control Lock is preset unlocked,
but can be locked.
To Lock or Unlock the Control:
1. Check that the microwave oven
is off.
2. Select CONTROL LOCK.
3. “Control Lock” will display.
4. Scroll up to unlock.
No keypads will function with the
controls locked.
Preferences
Times and Dates
Set time and date preferences.
NOTE: If user is connected to Wi-Fi, time and date will be set
automatically.
� Your Meal Times: Adjust when breakfast/lunch/dinner is shown
� Time
� Date
� Time Format (AM/PM vs 24 hour [Military Time])
Sound Volume
Set sound volume preferences.
� Timers and Alerts
� Buttons and Effects
Display Settings
Set the screen brightness.
� Display Brightness
Regional
Set regional preferences.
� Language: English, Spanish, or French
� Temperature Units: Fahrenheit and Celsius
Wi-Fi
� Connect to Network: Download the Whirlpool ® App from the
app store on your mobile phone. See the Connectivity Setup
sheet for more detailed instructions.
� SAID Code: The SAID code is used to sync a smart device
with your appliance.
� MAC Address: MAC Address is displayed for the Wi-Fi
module.
� Wi-Fi Radio: Turn Wi-Fi on or off.
Info
� Service and Support: Displays model number, Customer
Support contact info, and Diagnostics
� Store Demo Mode: Select Store Demo Mode to toggle Demo
Mode off and on
To Start Demo Mode
1. Select the Tools keypad.
2. Scroll and select INFO.
3. Select STORE DEMO MODE and select ON.
NOTE: The display screen will show the time (default screen/
standby mode).
4. Select the Tools keypad.
5. Select TRY THE PRODUCT or VIEW PRODUCT VIDEOS.
If the unit is in Demo Mode after power up, follow these steps
to exit the Demo Mode.
To Exit Demo Mode
1. Select TRY THE PRODUCT.
2. Scroll and select EXPLORE.
3. Select the Tools keypad.
4. Scroll and Select INFO.
5. Select STORE DEMO MODE and Select OFF.
6. Select YES on the confirmation screen.
� Restore Factory: This will restore your product to the original
factory default settings.
� Wi-Fi Terms and Conditions: www.whirlpool.com/connect.
� Software Terms and Conditions.
More Modes
Temperature Calibration
IMPORTANT: Do not use a thermometer to measure the oven
temperature. Elements will cycle on and off as needed to maintain
a consistent temperature but may run slightly hot or cool at any
point in time due to this cycling. Opening the oven door will affect
cycling of the elements and impact the temperature.
The oven provides accurate temperatures and has been
thoroughly tested at the factory. However, it may cook faster or
slower than your previous oven, causing baking or browning
differences. If necessary, the temperature calibration can be
adjusted in either Fahrenheit or Celsius.
On double ovens, the upper oven and the lower oven can each be
calibrated independently.
A minus sign means the oven will be cooler by the displayed
amount. The absence of a minus sign means the oven will be
warmer by the displayed amount.
Adjust the oven temp up to +/-30°F (+/-18°C). It is recommended
to make changes in 5°F (3°C) increments until desired results are
achieved.
To Adjust Oven Temperature Calibration:
1. Press the Tools keypad.
2. Select MORE MODES.
3. Select TEMPERATURE CALIBRATION.
4. Scroll from left to right to increase or decrease the
temperature.
IMPORTANT: Each oven calibration can be independently set.
Sabbath Mode
For guidance on usage and a complete list of models with
Sabbath Mode, visit
www.star-k.org .
The Sabbath Mode sets the oven to remain on in a bake setting
until disabled.
When the Sabbath Mode is activated, only the Bake cycle will
operate. All other cooking and cleaning cycles are disabled. No
tones will sound, and the displays will not indicate temperature
changes. When the oven door is opened or closed, the oven light
will not turn on or off, and the heating elements will not turn on or
off immediately.
Sabbath Mode is not available for the microwave oven.
If a cook timer is set, the countdown will appear. The timer will
count down once the timer is set.
