Built-In Electric Microwave Oven Combination Control Guide
FEATURE GUIDE
WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS, located in
your appliance's Owner's Manual, before operating this appliance.
This manual covers several models. Your model may have some or all of the items listed. Refer to these instructions or Frequently Asked
Questions (FAQs) section of our website at
www.whirlpool.com for more detailed instructions. In Canada, reference the Customer
Service section at www.whirlpool.ca.
KEYPAD FEATURE INSTRUCTIONS
Tools Oven Use
Functions Enables you to personalize the audible tones and oven operation to suit your needs. See
the “Tools” and “More Modes” sections.
Home Home Screen If pressed once, it enables the user to return to the “Cooking Methods” and “Assisted
Cooking” screen. If pressed twice, the time of day is displayed.
Favorites Favorites The Favorites keypad allows the user to save the cycles that they use on a frequent basis.
Oven Light Oven Cavity
Light The oven light is controlled by a keypad on the oven control panel. While the oven door is
closed, press the Oven Light keypad to turn the light on and off. When the oven door is
opened, the oven light will automatically turn on.
Oven Power/Cancel
OVEN
Oven Function
Power/Cancel The Oven Power/Cancel keypad turns the oven on and wakes it from Sleep mode.
If the oven is already on, the Oven Power/Cancel keypad stops any oven function except
the Clock, Timer, and Control Lock.
Microwave Power/
Cancel
MICROWAVE
Microwave
Function The Microwave Power/Cancel keypad turns the microwave oven on and wakes it from
Sleep mode. If the microwave oven is already on, the Microwave Power/Cancel keypad
stops any microwave oven function except the Clock, Timer, and Control Lock.
Touch Panel
The touch panel houses the control menu and function controls.
The touch keypads are very sensitive and require only a light
touch to activate. Scroll up, down, left, or right to explore the
different options and features.
For more information about the individual controls, see their
respective sections in this manual.
Display
The display is for both the menu and microwave oven function
controls. The touch panel allows you to scroll through the oven
menus. The display is very sensitive and requires only a light
touch to activate and control.
When a oven/microwave oven is in use, the display will show the
clock, mode, microwave oven temperature, kitchen timer, and
microwave oven timer, if set. If the oven/microwave oven timer is
not set, you can set it from this screen.
After approximately 2 minutes of inactivity, the display will go into
sleep mode and the display will dim. When the oven is in
operation, the display will remain bright. During use, the display
will show menus and the appropriate selections for the options
being chosen.
Display Navigation
If the microwave oven is off, touch the Oven Power or the
Microwave Power keypad for the desired oven to activate the
menu. From this screen, all automatic cooking programs can be
activated, all manual cooking programs can be set, options can be
adjusted, and instructions, preparation, and tips can be accessed.
Setup and Demo Mode
1. Select STORE DEMO MODE to enter Demo Mode.
OR
Select NEXT to enter into product use.
2. Follow the prompts on the display screen to select a
language, set up Wi-Fi/connect to network, accept the terms
of service, and set the time.
NOTE: The display screen will show the time and date
(default screen/standby mode).
3. Select TRY THE PRODUCT to explore various features and
options of the product.
OPTIONAL: Select VIEW PRODUCT VIDEOS to view a video
about how to navigate and interact with the product and
explore Voice Control.
4. Scroll and select EXPLORE.
5. Select the Tools keypad.
To exit Demo Mode, see the “Tools” section.
