4
Sound Volume
Sets the pitch of the tone to either high or low.
1. Press Settings - Clock until “SOUND VOLUME” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
End of Cycle Tone
Activates or turns off the tones that sound at the end of a cycle.
1. Press Settings - Clock until “END TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
Key Press Tones
Activates or turns off the tones when a keypad is pressed.
1. Press Settings - Clock until “KEYPRESS TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
Reminder Tones Disable
Turns off the short repeating tone that sounds every 1 minute after
the end of cycle tones.
1. Press Settings - Clock until “REMINDER TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
12/24 Hour Clock
1. Press Settings - Clock until “12/24 HOUR” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
12-Hour Shutoff
The oven control is set to automatically shut off the oven 12 hours
after the oven initiates a cook or clean function. This will not
interfere with any timed or delay cook functions.
1. Press Settings - Clock until “12 HR AUTO OFF” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
Languages - Scrolling Display Text
Language options are English and French.
1. Press Settings - Clock until “LANGUAGE” is displayed.
2. The current setting will be displayed.
3. Press the number keypad as instructed by the scrolling text to
select the new language.
4. Press OVEN - CANCEL to exit and display the time of day.
Oven Temperature Offset Control
IMPORTANT: Do not use a thermometer to measure oven
temperature. Elements will cycle on and off as needed to provide
consistent temperature, but they may run slightly hot or cool at
any point in time due to this cycling. Most thermometers are slow
to react to temperature change and will not provide an accurate
reading due to this cycling.
The oven provides accurate temperatures; however, it may cook
faster or slower than your previous oven, so the temperature can
be adjusted to personalize it for your cooking needs. It can be
changed to Fahrenheit or Celsius.
To Adjust Oven Temperature:
1. Press Settings - Clock until “TEMP CALIB” is displayed.
2. The current setting will be displayed.
3. Press OVEN - START to select the choice displayed in Step 2.
Wait several seconds for the display to change or press
OVEN - START, and then continue with Step 4.
4. Press the “3” keypad to increase the temperature in 5°F (3°C)
increments, or press the “6” keypad to decrease the
temperature in 5°F (3°C) increments. The range is from
-30°F to +30°F (-18°C to +18°C).
5. Press OVEN - START.
6. Press OVEN - CANCEL to exit and display the time of day.
Demo Mode
IMPORTANT: This feature is intended for use on the sales floor
with 120 V power connection and permits the control features to
be demonstrated without heating elements turning on. If this
feature is activated, the oven will not work.
1. Press Settings - Clock until “DEMO MODE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OVEN - CANCEL to exit and display the time of day.
Sabbath Mode
The Sabbath Mode sets the oven to remain on in a bake setting
until turned off.
When the Sabbath Mode is set, only the Bake cycle will operate.
All other cooking and cleaning cycles are disabled. No tones will
sound, and the displays will not indicate temperature changes.
When the oven door is opened or closed, the oven light will not
turn On or Off, and the heating elements will not turn On or Off
immediately.
NOTE: If a power failure happens while Sabbath mode is enabled,
lights will turn on when door is opened. If a power failure happens
while Sabbath mode bake is running, the oven will show Sabbath
mode is ON, but the bake cycle will not be on and the oven light
will turn on if the door is opened.
To Enable Sabbath Mode Capability (One Time Only):
1. Press Settings - Clock until “SABBATH” is displayed.
2. Press the “1” keypad. Sabbath Mode can be activated for
baking.
3. Press OVEN - CANCEL to save the setting and exit to display
the time of day.
NOTE: To disable the Sabbath Mode, repeat Steps 1 through
3 to change the status from “SABBATH ON” to “SABBATH
OFF”.
To Activate Sabbath Mode:
1.
Press Bake.
2.
Press the number keypads to set the desired temperature. If
the temperature entered is not in the range of the
temperatures allowed, the minimum or maximum allowed
temperature will be displayed. Enter a temperature in the
allowable range.
3.
Press OVEN - START for the selected oven.
For timed cooking in Sabbath Mode, press Cook Time, and
then press the number keypads to set the desired cook time.
The oven will remain on for 74 hours if no time is entered.
Press OVEN - START for selected oven.
4.
Press Settings - Clock. Three tones will sound. Then press
“7”. “SAb” will appear in the display.
5.
If the light is turned ON, then Sabbath mode bake is
activated, the oven light will stay ON whether door is opened
or closed.
