15
4. Close the oven door until it catches on the hinge stop
levers, locking the hinges at the proper angle for door
removal. The door will be open about 7 inches at the
top. This takes the spring tension off the hinges so the
door can be easily lifted out.
9 CAUTION
PINCH HAZARD
Closing the door 7” takes the pressure off of the
spring. If this isn’t done, the door can still be
removed but the latch will now slam shut and will
pinch or cut your hand.
5. The door is heavy. Use both hands to firmly grip it by
the sides. Do not grip the door by the handle.
Maintaining the door angle, lift the door straight up
approximately 3/4” to unhook the hinges from the
slots and then pull it out towards you until the hinges
are clear of the oven housing.
6. Place the door in a convenient and stable location for
cleaning.
Installing the Oven into the Cabinet
9 CAUTION
It is recommended to wear gloves and long sleeves
to protect hands and forearms from abrasion and
potential scratches during the lifting process. It is
also recommended to take off watches and jewelry
and to wear work shoes during installation for foot
protection.
9 CAUTION
Three people or proper equipment are needed to
safely lift the combination oven into the cabinet
opening.
NOTICE: To avoid damage to the door, do not lift, pull or
push the unit during installation by using any oven door
handle as a gripping point.
Lifting Recommendations
There is a ridge across the top front of the oven cavity.
Lift by grasping this ridge with one hand while placing the
other hand on the back of the unit (for helpers lifting from
the sides of the unit). If a third helper is lifting from the
front, both hands should lift by holding this ridge area.
9 CAUTION
DO NOT attempt to lift the unit by holding the oven’s
upper heating element.
