ANTI-TIP DEVICE
WARNING
Tip-over Hazard
A Child or adult can tip the range which can result in serious injuries or death.
Install the anti-tip device to the range and/or structure per installation instructions.
Engage the range to the Anti-tip device installed to the structure.
Re-engage the anti-tip device if the range is removed.
Failure to follow these instructions can result in death or serious injuries and/or burns to children
and adults.
To reduce the risk of tipping the range, the range must be secured by properly installed anti-tip device packed with the
range. See installation instructions shipped with the bracket for complete details before attempting to install.
All ranges can tip and cause injuries.
Here are two steps to install the anti-tip device
- Install the anti-tip bracket
- Install the anti-tip hook
Installing the anti-tip bracket
1. Drill 6 holes on the wall with correct sizes according to below table:
Wall Type Hole diameter
Wooden wall 0.1”
Concrete wall 0.31”
2. Please find the plastic sleeves in the part bag and put them inside the holes of the wall.
