13 EN
WATER CONDENSATION DRAINAGE
When there is excess water condensation inside the unit, the air conditioner stops running and
shows a warning light (the WATER FULL indicator
illuminates with a red light). This indicates that
the water condensation needs to be drained using the following procedures:
Unplug the unit from power source.
Place a drain pan under the lower rubber drain plug.
See diagram.
Remove the drain plug cap.
Water will drain out and collect in the shallow pan.
After the water is drained, replace the drain plug cap.
You can now turn on the unit. 1.
2.
3.
4.
5.
6.
Water may need to be drained in high humidity areas.
Manual Draining in Cooling, Dehumidifying Modes
IMPORTANT: It is NOT recommended to connect the drain hose for continuous drainage while the
unit is switched ON in air conditioning cooling mode. Doing so will reduce the cooling efficiency
of the Portable Air Conditioner. Only drain the water condensation when the unit is switched off.
Continuous drainage is only suitable when the unit is set up in Dehumidifier mode.
The water cannot be drained using the continuous drain option in heating* mode. In Heating mode,
the internal water tank collects condensation faster and may require more frequent emptying of
the tank in more humid rooms. It is recommended to use the heating mode in a room with 50 %
humidity or lower. Avoid operating moisture-creating products or appliances such as a humidifier or
a kettle when using the unit in heating mode.
Unplug the unit from power source.
Remove the upper drain plug cap.
Some residual water may spill so please have a pan to
collect the water.
Connect the drain tube to the upper drain plug.
See diagram.
The water can be continuously drained through the
drain tube into a floor drain or bucket.
Replace the drain plug cap.
You can now turn on the unit. 1.
2.
3.
4.
5.
6.
Continuous Draining in Dehumidifier Mode
Drain Tube (included):
Dia. 15mm
Length: 1m
Upper Rubber
Drain Plug
While using the unit in dehumidifier mode, continuous drainage is recommended.
Lower
Rubber
Drain Plug
Drain Pan
(not included)
*Applicable for models with Heating feature only.
