7
USE AND OPERATION
CONTROL PANEL
FUNCTION BUTTONS
EN
Press to turn ON/OFF the unit. The air vent will automatically swing open when the unit is turned
ON and automatically close when the unit is turned OFF.
RESTART DELAY
If the unit turns OFF while operating in COOLING / DEHUMIDIFYING / HEATING* modes, there will be
an approx. 3-minute delay to restart the air conditioner in COOLING / DEHUMIDIFYING / HEATING*
modes. This is a safety feature and added to help protect and extend the life of the compressor. After
3 minutes, you will be able to turn ON the unit as usual.
POWER CONTROL
(8) (9)
(4) (3) (2)
(1)
(6) (7) (5)
3 settings: High, Medium, and Low.
Note: Fan Speed cannot be adjusted in Sleep Mode and Dehumidifying Mode.
FAN SPEED CONTROL
1) Display screen 6) Mode Control
2) Power Control 7) Timer Control
3) Fan Speed Control 8) Sleep Control Indicator Light
4) Swing Control Indicator Light 9) Water Full Light
5) Timer / Temperature Set Controls
*Applicable for models with Heating feature only.
