WWW.WEBER.COM 31
ANNUAL MAINTENANCE
BURNER TUBE CLEANING
OR REPLACEMENT
Confirm that Grill is Off and Cool
A) Turn gas supply off at source and disconnect gas fitting.
B) Check that all burner control knobs are in the off
( ) position. Check by pushing burner control knobs in
and turning them clockwise until they stop. If they do
not turn, they are already off. If they do turn, continue
turning them clockwise until they stop; then they are
off.
C) Open lid and remove cookbox components.
Remove Burner Tubes
You will need: A 3/8" nut driver.
A) Remove the screw that holds the outside burner tube to
the cookbox (1) .
B) Rotate the outside burner tube 90°. Slide and lift burner
tube away from valve orifice and remove from cookbox.
(2)
C) Repeat this procedure for the inside burner tube (3) .
m CAUTION: Care must be taken when
removing or reinstalling burner tubes.
Do not force or bend the gas lines that
connect the control valves to the burner
tubes (4).
4
1
2
3
