DIGITAL CONTROL
4
Before using the grill, it is a good idea to familiarize yourself with
the control system.
1. WARNING ICON
Indicates an extreme temperature variance which could
indicate a fire, flame failure due to low fuel, auger disruption
or mechanical failure (open circuit, motor or fan failure).
WHEN ILLUMINATED GO DIRECTLY TO THE APPLIANCE
AND UNPLUG FROM POWER SOURCE IF NECESSARY .
2. MAIN TEMPERATURE
Displays current and set temperature in °F / °C
3. WIFI CONNECTED
Illuminated when pellet grill is connected to a WiFi network
(2.4ghz only).
4. BLUETOOTH CONNECTED
Illuminated when pellet grill is connected to smart device and
or home network.
5. 1 ST MEAT PROBE TEMPERATURE*
6. TIMER / STOP WATCH
7. 2 ND MEAT PROBE TEMPERATURE*
8. SMOKE BUTTON
For low and slow cooking this program will set the
temperature to 225°F / 107°C**
9. ROAST BUTTON
For roasting and baking this program will set the
temperature to 350°F / 176°C**
10. GRILL BUTTON
For direct grilling this program will set the
temperature to 600 ° F / 315 ° C**
11. SETTING BUTTON
Push SETTING button according to the number indicated
below to set the following features.
Meat Temperature Probe(s)
- Press SETTING button one time (1) for probe 1, two times (2)
for probe 2.
- Once probe is connected the temperature will appear on
screen.
- To set internal temperature doneness use control arrows to
set temperature then push SETTINGS once to set.
- Appliance will beep and check mark icon will appear on
screen when internal set temperature is reached.
*Note: When internal set temperature is reached, pellet grill
temperature will reduce and hold a 225°F(107°C)
Timer
- Press SETTING button three times (3).
- Use control arrows ▲/▼ to set timer then push SETTING
once to set.
Stop Watch
- Press SETTING button four times (4).
- Push control arrow UP arrow ▲ once to start.
- Push control arrow DOWN arrow ▼ once to stop.
- Hold both UP and DOWN arrows ▲/▼ to reset.
Display Brightness
- Press SETTING button five times (5).
- Use the control ar rows ▲/▼ to set display brightness,
then push SETTING once to set.
Change Temperature Units °F / °C
- Press and hold SETTING button for 5 seconds to set pellet
grill to Fahrenheit ( ° F) or Celsius ( ° C).
12. CONTROL ARROWS ▲/▼
Adjust temperature in 5 degree increments using the control
arrows ▲/▼ then push SETTING once to s et
Hold down the control arrows ▲/▼ to quickly adjust the
temperature as a rapid scroll.
Note: Display will return to current temperature in °F / °C.
13. THERMOMETER PORTS 1 AND 2
14. POWER BUTTON
*Note: Illuminated check mark indicates target internal
temperature achieved.
**Note: Expect temperature variance to occur when reaching
and holding desired setting.
Thermometer probe passing through the side of the smoker
