5
Figure 2
Figure 3
Standard Installation Dimensions and Clearances
Appliance Dimensions
Microwave Built-in Drawer Measurements
23 7 /
8
"
(606 mm)
21 5 /
8
"
(549 mm) Approx. 46"
(1,168.4 mm)
1 11 /
16
"
(39 mm)
23 3 /
8
"
(594 mm)
21 7 /
8
"
(556 mm)
38 3 /
8
"
(974 mm)
14 5 /
8
"
(371 mm)
16 5 /
16
"
(414 mm)
14 5 /
8
"
(372 mm)
23 1 /
2
"
(597 mm)
24" or 27"
(610 or 686 mm)
36"
(914 mm)
22 1 /
8
"
(562 mm)
Frontview cut out
* Suggested location of electrical outlet
** Anti-Tip Block
*** Base should support up to 100 lbs
14 13 /
16
"
(376 mm)
6" (152 mm)
4" (102 mm)
*
**
***
5" (127 mm)
3 1 /
2
" (89 mm)
1 1 /
2
" (38 mm)
7 /
8
"
(22 mm)
overlap
1 /
2
"
(13 mm)
visible
area
7 /
8
"
(22 mm)
overlap
1 /
16
"
(2 mm)
overlap
1 7 /
16
"
(36 mm)
overlap
