English 7
Frontview cut out
* Suggested location of electrical outlet
** Anti-Tip Block
*** Base should support up to 100 lbs
*
**
***
A
B
C
D
E
G
H
L
O
N
J
K
L
M
I
F
Figure 3
Standard Installation Dimensions and Clearances
Appliance Dimensions
Drawer Microwave Measurements
A
C
D
B
F
G
H
I
E
A. HMD8451UC (24") 23
7
/
8
" (606 mm)
HMD8053UC (30") 30" (762 mm)
B. 16
5
/
16
" (414 mm)
C. 23
3
/
8
" (594 mm)
D. 21
7
/
8
" (556 mm)
E. 38
3
/
8
" (974 mm)
F. 21
5
/
8
" (549 mm)
G. 14
5
/
8
" (371 mm)
H. 1
11
/
16
" (39 mm)
I. Approx. 46" (1,168.4 mm)
A. HMD8451UC (24") 24" or 27" (610 or 686 mm)
HMD8053UC (30") 30" (762 mm)
B. 36" (914 mm)
C. 23
1
/
2
" (597 mm)
D. 14
5
/
8
" (372 mm)
E. 4" (102 mm)
F. 6" (152 mm)
G. 5" (127 mm)
H. 3
1
/
2
" (89 mm)
I. 1
1
/
2
" (38 mm)
j. 22
1
/
8
" (562 mm) min.
28
5
/
16
" (719 mm) max.
K. 14
13
/
16
" (376 mm)
L.
7
/
8
" (22 mm) overlap
M.
1
/
2
" (13 mm) visible area
N.
1
/
16
" (2 mm) overlap
O. 1
7
/
16
" (36 mm) overlap
Figure 2
