English 4
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Clearances and
Dimensions
• For safety considerations, do not install Drawer
Microwave in any combustible cabinetry which is not
in accord with the stated clearances and dimensions
in the "Drawer Microwave Measurements” section
following. See Figure 3 (standard installation) or Figure
4 (flush installation).
• Dimensions that are shown in Figure 3 (standard installa-
tion) or Figure 4 (flush installation) must be used. Given
dimensions provide minimum clearance. Locate electrical
outlet in the shaded area in the upper left-hand corner of the
cutout. See Figure 6.
• Supporting surface must be solid and level. Pay special
attention to the floor of the cabinet opening on which
the Drawer Microwave will sit. The floor of the open-
ing should be constructed of plywood strong enough
to support the weight of the oven (approximately 100
pounds).
• Check the location where the Drawer Microwave will be
installed for proper electrical supply.
• Your oven can be built into a cabinet or wall as a stand-
alone unit or under a built-in gas or electric wall oven and
the followings:
GAS
COOKTOPS
ELECTRIC
COOKTOPS
INDUCTION
COOKTOPS
NGM5055UC
NGM5655UC
NGM8055UC
NGM8065UC
NGM8655UC
NGM8665UC
NGMP055UC
NGMP655UC
NEM5066UC
NET8066UC
NET8066CUC
NETP066CUC
NEM5666UC
NET8666UC
NET8666CUC
NETP666CUC
NIT5066UC
NIT8066UC
NIT8066CUC
NITP066UC
NITP066CUC
NIT5666UC
NIT8666UC
NIT8666CUC
NITP666UC
NITP666CUC
• Check to be sure that there is a clearance of 2 inches or
greater between the top of the Drawer Microwave unit and
the bottom of a built-in wall oven above it.
• The microwave interior will accommodate a 9" x 13"
oblong dish or a bag of microwave popcorn.
• INSTALLER: LEAVE THESE INSTRUCTIONS WITH
THE APPLIANCE AFTER INSTALLATION IS COM-
PLETE.
IMPORTANT: SAVE THESE INSTRUCTIONS FOR THE
LOCAL ELECTRICAL INSPECTOR'S USE.
WARNING
If the information in this manual is not followed
exactly, fire or shock may result causing property
damage or personal injury.
WARNING
Do not repair, replace or remove any part of the
appliance unless specifically recommended in
the manuals. Improper installation, service or
maintenance can cause injury or property damage.
Refer to this manual for guidance. All other
servicing should be done by a qualified technician.
Appliance Handling Safety
Unit is heavy and requires at least two people or proper
equipment to move.
Do not lift appliance by door handle.
Hidden surfaces may have sharp edges. Use caution
when reaching behind or under appliance.
State of California Proposition 65
WARNING
This product contains chemicals known to the State
of California to cause cancer, birth defects or other
reproductive harm.
Electric Safety
WARNING
Before you plug in an electrical cord or turn on
power supply, make sure all controls are in the OFF
position.
WARNING
The appliance must be disconnected from the
source of supply before attempting the installation.
