Medal Sports 58106 - Manuel (Page 13)

FIG.11
FIG. 11
12
13
21
12
21
25
1
2
38
x4 x8
x2
22
38
25 x4 27
15. With the help of another adult, Attach the Backboard(#21) to
the Board L Tubes(#1) using Bolts(#25), Washers(#22) and
Nuts(#27). At each bottom hole of the backboard,attach the
tabs of Ball Return Net(#13) using Bolts(#25), Washers(#22)
and Nuts(#27) .
16. Insert the Lock Pins (#38) to the Left and Right L Tubes (#5
and #6) .
Tab
25 22
22
27
1
22
27 22
