FIG.8
11. Attach the Rim Assemblies (#17) and Rim Support Plates
(#18) to the Backboard (#21) using the Bolts (#23), washers
(#22) and Nuts (#27). And then attach the Switch Sensor (#15)
to the Backboard (#21) using the Bolts (#23), washers (#22)
and Nuts (#27). Make sure that you use washer on both sides
of the backboard.
FIG. 8
9
x16 x32 22 23 x16 27 x1 21
x2 15 x2 17 x2 18
27 22
18
15 17
23
22
15
17
22
23
21
18
22
27
