9
Cutout Height is between 50¹⁄
2
" (128.2 cm)
and 51¹⁄
8
" (129.9 cm)
1. Using 2 or more people, place the oven on its back on a
covered surface.
2. Install a foot on the left rear spacer using a #8-18 x ³⁄
8
"
screw.
NOTE: Position the foot so the long side of the foot is
facing toward the top of the oven.
A. Spacer
B. Foot
C. #8-18 x ³⁄
8
" screw
3. In the same manner, install a foot on the right rear of the
oven.
4. Install a front foot on the left front spacer using a #8-18 x ³⁄
8
"
screw.
NOTE: Position the foot so the long side of the foot is facing
toward the oven as shown.
A. Front foot
B. #8-18 x ³⁄
8
" screw
C. Spacer
5. In the same manner, install a front foot on the right front of
the oven.
6. Using 2 or more people, place the oven in its upright
position.
7. Go to the “Make Electrical Connection” section.
Cutout Height is between 51³⁄
16
" (130.0 cm)
and 52³⁄
16
" (132.6 cm)
1. Using 2 or more people, place the oven on its back on a
covered surface.
2. Install a foot on the left rear spacer using a #8-18 x ³⁄
8
"
screw.
NOTE: Position the foot so the short side of the foot is facing
toward the top of the oven.
3. In the same manner, install a foot on the right rear of the
oven.
A. Spacer
B. Foot
C. #8-18 x ³⁄
8
" screw
A
B
C
C
B
A
A
B
C
