5
INSTALLATION INSTRUCTIONS
Prepare Built-In Microwave/Oven
Combination
1. Decide on the final location for the oven. Locate existing
wiring to avoid drilling into or severing wiring during
installation.
2. To avoid floor damage, set the oven onto cardboard prior to
installation. Do not use handle or any portion of the front
frame for lifting.
3. Remember to remove bottom vent from the foam packing on
top of oven.
4. Remove the shipping materials and tape from the oven.
5. Remove the hardware package from inside the bag
containing literature.
6. Remove and set aside racks and other parts from inside the
oven.
7. Move oven and cardboard close to the oven’s final location.
Remove Oven Door(s)
IMPORTANT: Use two hands to remove oven door.
1. Prior to removing the oven door, prepare a surface where you
will place it. This surface should be flat and covered with a
soft blanket, or use the corner posts from your packaging
material.
2. Open the oven door.
3. Locate the oven door hinge locks in both corners of the oven
door, and rotate the hinge locks toward the oven door to the
unlocked position. If the door hinge lock is not rotated fully
(see illustration B), the door will not remove properly.
4. Partially close the door to engage the door latch locks. The
door will stop at this point.
5. Using two hands, grasp the edges of the oven door. Lift and
pull the oven door toward you and remove. You may need to
gently shift door from side to side as you pull.
6. Set the oven door(s) aside on the prepared covered work
surface, with the oven door resting on its handle.
7. To continue with the oven installation, go to the “Positioning
Oven Feet for Multiple Cabinet Cutout Heights” section.
Replace Oven Door(s)
IMPORTANT: Do not replace the oven door(s) until after the oven
has been installed into the cabinet.
1. Using two hands, grasp side edges of door at the midpoint.
Face the oven cavity.
2. Locate the slots on each side of the oven cavity for the door
hinge locks.
A. Oven door hinge lock in
locked position
B. Oven door hinge lock in
unlocked position
WARNING
Excessive Weight Hazard
Use two or more people to move and install oven.
Failure to do so can result in back or other injury.
A B
A. Slot in the oven cavity for
door hinge lock
A
