7
Electronic Oven Controls
Control Display
The display will flash when powered up or after a power loss. Press
CANCEL to clear. When the oven is not in use, the time of day is
displayed. If the range is in Energy Save mode, the display will be
blank when not in use.
Tones
Tones are audible signals, indicating the following:
One Tone
■ Valid keypad press
■ Oven is preheated (long tone)
■ Function has been entered
■ Reminder, repeating each minute after the end-of-cycle tones
Three Tones
■ Invalid keypad press
Four Tones
■ End of cycle
Use the Settings/Clock keypad to change the tone settings.
Energy Save
The Energy Save mode puts the range into sleep mode and
reduces energy consumption.
To Activate the Energy Save Mode:
1. Press and hold SETTINGS/CLOCK for 3 seconds. “Energy
saver on.” will appear in the display.
2. The setting will be activated after 5 minutes.
To Deactivate the Energy Save Mode:
1. Press and hold SETTINGS/CLOCK for 3 seconds. “Energy
saver off.” will appear in the display.
2. The clock will reappear in the display, and the range can be
operated as usual.
Settings
Many features of the oven control can be adjusted to meet your
personal needs. These changes are made using the Settings/Clock
keypad.
Use the Settings/Clock keypad to scroll through the features that
can be changed. Each press of the Settings/Clock keypad will
advance the display to the next setting. After selecting the feature
to be changed, the control will prompt you for the required input.
Then press START or CANCEL to exit and display the time of day.
Details of all of the feature changes are explained in the following
sections.
Press CANCEL to exit Settings.
Clock
The Clock can use a 12- or 24-hour cycle.
1. Press SETTINGS/CLOCK until “CLOCK” is displayed.
2. Press START to change the time.
3. Press “3” for AM or “6” for PM.
4. Use the number keypads to set the time of day.
5. Press START or CANCEL to exit and display the time of day.
Fahrenheit and Celsius
The temperature is preset to Fahrenheit, but can be changed to
Celsius.
1. Press SETTINGS/CLOCK until “TEMP UNIT” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press START or CANCEL to exit and display the time of day.
Audible Tones Disable
Turns off all tones, including the end of cycle tone and key press
tones. Reminder tones are still active when all tones are disabled.
1. Press SETTINGS/CLOCK until “SOUND” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press START or CANCEL to exit and display the time of day.
Sound Volume
Sets the volume of the tone to either high or low.
1. Press SETTINGS/CLOCK until “SOUND VOLUME” is
displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press START or CANCEL to exit and display the time of day.
End of Cycle Tone
Activates or turns off the tones that sound at the end of a cycle.
1. Press SETTINGS/CLOCK until “END TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press START or CANCEL to exit and display the time of day.
Key Press Tones
Activates or turns off the tones when a keypad is pressed.
1. Press SETTINGS/CLOCK until “KEYPRESS TONE” is
displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press START or CANCEL to exit and display the time of day.
START
(hold 3 sec
to lock)
Oven control
lockout 1. Check that the oven is off.
2. Press and hold START (hold 3 sec to lock) for 3 seconds.
3. A tone will sound, and “Control Locked” will scroll, and then “Locked” will be displayed.
4. Repeat to unlock. No keypads will function with the controls locked. The cooktop functions
are not affected by the oven control lockout.
SETTINGS/
CLOCK Energy save Press and hold SETTINGS/CLOCK for 3 seconds to change status. The display will scroll
“Energy saver on.” or “Energy saver off.”
If Energy Save is on, the range will go into sleep mode after 5 minutes of inactivity. Any keypad
press will activate the display. If Energy Save is off, the display will be on at all times.
KEYPAD FEATURE INSTRUCTIONS
