BIXOLON SRP-275II - Manuel (Page 7)

Rev. 1.04 - 7 -
SRP-275II
■ Table des matières
1. Installation de l’imprimante ············································································· 8
1-1 Déballage ····························································································· 8
1-
2 Choisir l’emplacement de l’imprimante ······················································· 8
1-3 Utilisation du panneau de contrôle ····························································· 9
2. Connexion des câbles ·················································································· 10
2-1 Connexion de la sortie-secteur ······························································· 10
2-
2 Connexion du câble d’interface et du câble du tiroir dévidoir ························· 10
2-2-1 Interface série (RS-232C) ································································· 11
2-2-2 Interface parallèle (IEEE1284) ··························································· 12
2-2-3 Interface USB ················································································ 13
2-2-4 Interface Ethermet ·········································································· 13
2-2-5 Drawer kick-out ·············································································· 13
3. Installation des commutateurs ······································································ 14
3-1 Installation du commutateur DIP ····························································· 14
3-1-1 Paramètres du commutateur DIP en mode Citizen (iDP 3550) ················· 15
3-1-2 Paramètres du commutateur DIP en mode Star (SP500) ························ 16
3-1-3 Réglages du commutateur DIP ·························································· 17
3-2 Configuration des commutateurs de cartes mémoire ··································· 18
3-2-1 Configuration du commutateur carte mémoire en mode Star ··················· 20
4. Installation de la cartouche de ruban ····························································· 26
5. Installation du rouleau de papier ··································································· 27
6. Installation du montage mural (facultatif) ······················································· 28
7. L’auto-test··································································································· 29
8. Impression des codes et caractéres en hexadécimal ······································· 30
9. Fiche technique ··························································································· 31
9- 1 Spécification d’impression ····································································· 31
9-2 Spécifications du papier ········································································ 31
9-3 Spécifications pour la cartouche de ruban ················································· 31
9-4 Caractéristiques électriques ··································································· 32
9-5 Fiabilité ······························································································ 32
9-6 Conditions environnementales ································································ 32
9-7 Dimensions et poids ············································································· 33
9-8 Utilités facultatives ··············································································· 33
10. ANNEXX - Dépannage ················································································· 34
10-1 Clignotement du voyant ERROR ··························································· 34
10-
2 L’imprimante n’imprime pas ·································································· 35
10-
3 Interruption de l’impression ·································································· 36
10-
4 Vérification du fonctionnement de l’imprimante ········································· 36
10- 5 L’impression est médiocre ···································································· 36
