Installation
WHEN ALL HOOKUPS ARE
COMPLETED
Make sure all controls are left in the off position.
Make sure the flow of ventilation air to the range is
unobstructed.
Check that all packing materials and tape have been
removed. This will include tape on metal panel,
adhesive tape, wire ties, cardboard, and protective
plastic. Failure to remove these materials could result
in damage to the appliance once the appliance has
been turned on and surfaces have heated.
9
REPLACE OVEN DOOR(S)
Skip this step if oven doors are in place.
I MPORTANT: Do not lift the door by the handle.
To replace the oven doors:
Ŷ Firmly grasp the door at the top sides. This is critical.
Ŷ$SSURDFKWKHUDQJHZLWKWKHGRRUDQJOHGLQD
vertical position.
Ŷ*XLGHWKHKLQJHVLQWRWKHVORWV
Ŷ3XVKWKHGRRULQILUPO\ZKLOHRSHQLQJ
Ŷ2QFHLQSRVLWLRQRSHQWKHGRRUFRPSOHWHO\3XVK
the hinge locks back in toward the front frame.
CAUTION
Take care when replacing the
oven doors. If the hinge latch is not securely locked,
the hinge may snap back and separate. If the hinge
separates, you must apply pressure (possibly with your
foot) to press it back together and then engage the
hinge latch.
