Menu Introduction
Most parameters are accessed and changed via an easy-to-use menu. The flow chart below outlines the entire DAC-1721
menu path. Each menu is described throughout this section.
The procedure and the operation mode are described in the common paragraph of the DENSITÉ Manual. The menu
organization is made out of a main menu and several sub-menus. A press on the [SELECT] front panel push button accesses to
the menu. A lack of activity turns off the display. Default values are written with bold characters.
STATUS
FACTORY DEFAULT
FPGA FAILURE, REAR PANEL ERROR, NO LOCK, BIPHASE CODING, PARITY,
CRCC, SLIPPED SAMPLE, CONFIDENCE, INVALID SAMPLE, NON AUDIO,
OVERLOAD (L,R,L&R), NO SIGNAL(L,R,L&R), MUTE(L,R,L&R), TONE, ALL OK
RESTORE Vxxx
CHANNEL STATUS
CHANNEL 1
CHANNEL 2
CHANNEL 1
CHANNEL 2
MODE PROFESSIONAL, CONSUMER
AUDIO MODE AUDIO, DATA
CHANNEL MODE Not indicated, TWO CHANNEL, SINGLE, STEREO, PRI/SEC, Other
EMPHASIS Not indicated, NONE, 50-15µs, CCITT J17
FREQUENCY Not indicated, 32k, 44k1, 48k, 88k2, 96k, Other
WORD LENGTH Not indicated, 16, 17, 18, 19, 20, 21, 22, 23, 24 bits
ORIGIN 4 ASCII characters
DESTINATION 4 ASCII characters
TONE CHANNEL 1&2
CHANNEL 1
CHANNEL 2
OFF, EBU
LEFT & RIGHT LEVEL CHANNEL 1&2
CHANNEL 1
CHANNEL 2
-96, ..., 0, ..., +12 LEFT
RIGHT
LEFT & RIGHT MUTE CHANNEL 1&2
CHANNEL 1
CHANNEL 2
OFF, ON LEFT
RIGHT
0 dBFS SETTING 0, 1, 2, ..., 24, ..., 28
DE-EMPHASIS CHANNEL 1&2
CHANNEL 1
CHANNEL 2
OFF, AUTO, 50-15 µs
NO SIGNAL DELAY 0, ..., 15, ..., 255
SIGNAL THRESHOLD -72, -66, -60, -54, -48
CONFIGURE ALARM NO LOCK ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
BIPHASE CODING ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
PARITY ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
CRCC ERROR ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
SLIPPED SAMPLE ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
CONFIDENCE ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
INVALID ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
NON AUDIO ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
NO SIGNAL ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
TONE ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
OVERLOAD ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
MUTE ALARM LEVEL
ALARM REPORT NONE, GPI
GREEN, YELLOW, RED, FLASH RED
