18
1) Description of the control panel
2) Use on electricity for versions:
- All electric with or without fan.
- Mixed with fan in SUMMER position.
2-1) Setting the CONFORT temperature
It is the temperature desired when the room is occupied.
a) Set the switch to to the ON position, the indicator lights.
b) Set knob , the indicator lights when the ambient temperature is below that desired.
c) Wait a few hours for the temperature to stabilise.
If the temperature setting does not suit you, adjust it using the adjusting screw .
2-2) Standby (Hors Gel) Mode
It is the mode enabling to maintain a temperature of approximately 7°C in the room in case of pro-
longed absence from the house.
a) Leave switch on the Marche position.
b) Set the knob to .
2-3) Turbo mode
It is the mode enabling to set the device into Forced Operation, ensuring prompt temperature
increase in the room over the time defined (maximum power for conventional models and fan acti-
vation point for models with ventilating fan).
a) Leave the switch on the Marche position.
b) Select the time for the Turbo using the knob .
c) Press the command , the indicator and lights.
d) The TURBO mode can be interrupted manually before the end of the time set. In order to do this,
press the command again.
NB: On a piloted or independently programmed appliance, only the Stop and Anti-frost instructions
have priority when the TURBO mode is activated (the other instructions are ineffective).
USE OF THE CONTROL BOX
Temperature setting knob with Hors Gel
position and ability to restrict the range.
Time adjustment knob TURBO 1/4h, 1/2h,
1h, 2h.
Power On indicator
TURBO indicator
TURBO control
Heating ON/OFF switch
Heating indicator
