Maytag MVWB350YQ Installation - Manuel (Page 8)

8
Plug into a grounded
3-prong outlet
5.
COMPLETE INSTALLATION
CHECKLIST
■ Check electrical requirements. Be sure you have correct
electrical supply and recommended grounding method.
See “Electrical Requirements.”
■ Check that all parts are now installed. If there is an extra
part, go back through steps to see what was skipped.
■ Check that you have all of your tools.
■ Keep the foam packing ring from the washer tub for future
relocation of the washer. Dispose of/recycle all packaging
materials.
■
Check that both water faucets are on.
■ Check for leaks around faucets and inlet hoses.
■ Remove film from console and any tape remaining
on washer.
■
Check that washer is plugged into a grounded
3-prong outlet.
■ Read “Washer Use” in your “Use and Care Guide.”
■ To test and clean your washer, measure 1/2 of normal
recommended amount of High Efficiency (HE) powdered
or liquid detergent for a medium-size load and pour it into
detergent dispenser. Close lid. Press POWER. Select
a normal cycle and press START. Allow it to complete
one whole cycle.
If washer is not level, use a 9/16" or 14 mm open-end or
adjustable wrench to turn jam nuts clockwise on feet until they
are about 1/2" (13 mm) from the washer cabinet. Then turn the
leveling foot clockwise to lower the washer or counterclockwise
to raise the washer. Recheck levelness of washer and repeat
as needed.
HELPFUL TIP: You may want to prop up front of washer
about 4" (102 mm) with a wood block or similar object that
will support weight of washer.
3.
Adjust leveling feet
Jam nut
When washer is level, use a 9/16" or 14 mm open-end
or adjustable wrench to turn jam nuts counterclockwise
on leveling feet tightly against washer cabinet.
HELPFUL TIP: You may want to prop washer with
wooden block.
4.
Tighten leveling feet
Jam nut
