6
Loosen bolts with a 13 mm (1/2") wrench.
Slide each bolt and spacer to center of hole. Pull bolts and
plastic spacers from back of washer. Save transport bolts
and spacers. Contact a qualified servicer if washer is to be
transported.
Close bolt holes on cabinet back with transport bolt hole plugs
included with washer parts.
Pull power cord through opening in rear panel and close
holes (2) with attached white plastic cap.
NOTE: If washer is transported at a later date, call a certified
technician to properly set up washer for relocation, to avoid
suspension and structural damage.
CONNECT DRAIN HOSE
Gently place power cord over top of washer to allow free
access to back of washer.
Squeeze hose clamp tabs with pliers and slide over end of
drain hose. Slide drain hose onto washer elbow connector
and secure with clamp.
For a laundry tub or standpipe drain, go to step 8.
You may need additional parts with separate directions.
See Floor drain system under “Alternative Parts”.
3.
Remove transport bolts from
washer
4.
Cover bolt holes with transport
bolt hole plugs
6.
Place power cord over top
5.
Remove power cord
7.
Attach drain hose to drain port
