1-4. REAR PANEL DESCRIPTION
DC-IN: DC power connector.
RS-232: RS-232 communication port.
LAN: LAN communication port.
Chapter 2 : CONNECTING & OPERATING MODE (refer to the user's manual of the controlled device)
Chapter 3 : UPDATING THE REMOTE KEYPAD
The REMOTE KEYPAD can be updated thanks a COMPUTER (PC) via its RS-232 communication port only.
3-1. CONNECTIONS
c Connect the "RS-232" connector of the REMOTE KEYPAD to the SERIAL port of your COMPUTER with the
update cable (DB9 M/M crossed cable).
d Connect the power supply of the REMOTE KEYPAD to a power outlet.
3-2. UPDATE INSTRUCTIONS
c Open the file "RK8022 Updater" (in Start > Program > ANALOGWAY > RK8022).
d In the Port menu select the COM port connected to the device.
e Click on "START" on the SOFTWARE.
f Press the ENTER button of the RK8022, and connect simultaneously the DC plug of the power supply to the
REMOTE KEYPAD DC-IN connector. The LCD screen displays Downloading, and the upgrade will start. Then you
can release the ENTER button.
g When the software displays "Program operation completed", disconnect the update cable and the DC plug. Then
connect again the DC plug to the RK8022.
h Click on the "Quit" button to close the update SOFTWARE.
NOTE: Your REMOTE KEYPAD is now ready to work.
NOTE: The updater files are available on our web site: http://www.analogway.com
Chapter 4 : TECHNICAL SPECIFICATIONS
Power Supply: + 9 Vdc.
Storage Temperature: - 25 °C to + 85 °C (- 13 °F to + 185 °F).
Maximum ambient operating temperature: < 40 °C (< 104 °F).
Hygrometry: 10% to 80% (without condensation).
Dimensions: RK8022-T: W 220 x D 130 x H 102 mm.
W 8.9" x D 5.1" x H 4".
Rackmount compatible (3U height, ½U width).
RK8022: W 220 x D 130 x H 67 mm.
W 8.9" x D 5.1" x H 2.6".
Rackmount compatible (3U height, ½U width).
Weight: 1 kg / 2.2 lbs.
Chapter 5 : WARRANTY
Analog Way warrants the product against any defects in material and workmanship for a period of three years from the date of
purchase (back to the factory).
In the event of any malfunction during the warranty period, Analog Way will, at its discretion, repair or replace the defective
unit, including free material and labor.
This warranty does not apply if the product has been :
- improperly installed or abused,
- handled with improper care,
- used or stocked in abnormal conditions,
- modified, opened,
- damaged by fire, war, or Natural disasters (Acts of God).
In no way shall Analog Way be responsible for direct or indirect loss of profit or consequential damages resulting from any
defect in this product.
In case of any problem, get the serial number of the unit, a description of the problem, and then call your authorized dealer.
