Fulgor Milano 700 Series 24 Inch Single Convection Electric Wall Oven Use and Care Manual - Manuel (Page 32)

EN
30
19 - Setting The Self Cleaning Mode
To Set the Self-Clean Mode
1. Press key and confirm with key .
2. A message appears on the screen to remove all objects or
accessories from the compartment.
3. Press the key to start door lock and cleaning cycle.
4. The clean time is displayed automatically, its standard value
is 3 hours.
11:00 am
SELF CLEAN
END
START
4:30 pm
1:30 pm
Start
STOP
5. At the end of the programmed cleaning time, the oven will
automatically turn off.
• To stop the cleaning mode at any moment, press key.
• The Self Cleaning cycle cannot be selected if the door
is open.
• If the door is in the open position when the function has
already been selected and the key is pressed the
latch doesn’t move, the “PADLOCK” icon will flash until
the door will be closed and the lock motor stops. When
the “CLOSED PADLOCK” it is displayed, the door cannot
be opened.
• Check that the door has been locked, if door does not
lock, press key and do not start self-clean; phone for
service
• Do not attempt to open the door while the cleaning cycle
is running and the door is locked.
To Change the Cleaning Time
1. To change the setting from 3 hours, select either 2 hours for
light soil immediately after starting.
2. To change the hours, touch the key, select and
confirm with the key (the hours will flash), use or
keys to change the value, then press to confirm the new
value.
3. To select the minutes, touch the key (the minutes will
flash), use or keys to change the value, then press
to confirm the new value.
To Delay the Start of Cleaning
1. Follow steps 1 through 3 above.
2. Touch the key and verify that “STOP TIME” appears on
the display. The hours will begin flashing, use or keys
to change the value, then press to confirm the new value.
3. To select the minutes, touch the key (the minutes will
flash), use or keys to change the value, then press
to confirm the new value.
11:00 am
SELF CLEAN
END
TIME
2:00 pm
03:00
STOP
TIME
8. When the delay time expires, self-cleaning will start.
9. At the end of the programmed cleaning time, the oven will
automatically turn off.
CAUTION
Keep in mind that the oven door will remain locked until it is
safe enough to open. The lock symbol will disappear from
the display when the door lock is released.
You will still need to exercise caution when the door lock is
released because the inside of the oven may still be hot.
After the self-clean cycle is complete the oven control monitoring
the internal temperature and the following messages will be
displayed:
• From the 460°C/860°F to 270°C/518°F= “End Self
Cleaning”
• From the 270°C/518°F to 50°C/122°F= “Waiting to
Clean”
• From the 50°C/122°F to 25°C/77°F= “Remove Residues”
(Press ON/OFF key to clear the message).
You may notice a powder ash residue in the bottom of the oven
after self-cleaning. This condition is normal. Use a damp cloth
or sponge to wipe up the residue after the oven cools down.
Self-cleaning Tips:
• If any soil remains in the oven after the self-clean cycle is
complete, you may repeat the cycle if you want.
• Self-clean the oven regularly to prevent excessive soil build-
up. Doing so will make the self-clean cycle work better and
reduce smoke and odors.
